FIG.717A FRONT BUMPER

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	71711M50S10-799	BUMPER, FRONT (PRI3Y)	1	Rp2.323.500	PAINT TO MATCH
2	71712M50S10-000	CAP, FRONT BUMPER NO.1	1	Rp8.500
3	71713M50S10-000	CAP, FRONT BUMPER NO.2	1	Rp63.000
4	71714M50S00-ZAM	GARNISH, FR BUMPER UPPER RH (BLACK)	1	Rp405.000
5	71715M50S00-ZAM	GARNISH, FR BUMPER UPPER LH (BLACK)	1	Rp411.000
6	71716M50S20-000	GARNISH, FR BUMPER LICENSE	1	Rp38.500
7	71721M50S10-5PK	GRILLE, RADIATOR LOWER (BLACK)	1	Rp115.500
8	71731M50S00-000	HOLDER, FR BUMPER SIDE RH	1	Rp32.000
9	71732M50S00-000	HOLDER, FR BUMPER SIDE LH	1	Rp32.000
10	71740M50S30-C48	GRILLE, RADIATOR UPPER (CHROME/BLACK)	1	Rp530.500
11	77811-65J00-0PG	.EMBLEM, 3K S (CHROME)	1	Rp131.500
12	71751M50S40-5PK	BEZEL, FRONT FOG LAMP RH (BLACK)	1	Rp57.000
13	71761M50S40-5PK	BEZEL, FRONT FOG LAMP LH (BLACK)	1	Rp57.000
14	71770M50S00-ZSC SUB: 71770M50S00-799	EXTENSION, FR BPR LWR (PRI3Y)	1	Rp1.310.500
15	71772M50S00-000	.SPACER, FR BUMPER LOWER EXT	2	Rp7.000
16	09132M05063-000	.SCREW (5X16)	2	Rp5.500
17	71781M50S00-000	REINF, FRONT BUMPER RH	1	Rp21.500
18	71782M50S00-000	REINF, FRONT BUMPER LH	1	Rp21.500
19	09136-05068-000	SCREW (5X20)	2	Rp15.000
20	09136-05075-000	SCREW (5X16)	4	Rp35.500
21	09148M05071-000	NUT	1	Rp6.000
22	09148M05072-000	NUT	2	Rp5.500
23	09148-06022-000	NUT	2	Rp27.000
24	09409M08006-000	CLIP	2	Rp5.000
25	09409M08006-000	CLIP	2	Rp5.000
26	01551-0616C-000	BOLT	4	Rp14.500
27	03541-0512B-000 SUB: 03541B0512BN000	SCREW	6	Rp4.000
28	03541-0516A-000	SCREW	7	Rp3.500
29	03541-0516A-000	SCREW	2	Rp3.500
30	03541-0516A-000	SCREW	4	Rp3.500
31	03541-0516A-000	SCREW	3	Rp3.500
32	03541-0516A-000	SCREW	10	Rp3.500
33	03541-0516A-000	SCREW	3	Rp3.500
