FIG.811A REAR DOOR REGULATOR

FIG.811A REAR DOOR REGULATOR

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	83501M68P11-000	REGULATOR ASSY, RR WINDOW RH	1	Rp318.500
2	83502M68P11-000	REGULATOR ASSY, RR WINDOW LH	1	Rp318.500
3	02162-0612A-000	SCREW	4	Rp11.000
4	02162-0612A-000	SCREW	6	Rp11.000
5	83671M68P00-000	RUN, RR DR GLASS RH	1	Rp367.500
6	83675M68P00-000	RUN, RR DR GLASS LH	1	Rp367.500
7	83831M68P10-000	WEATHERSTRIP, RR DR OUT RH	1	Rp280.500
8	83841M68P10-000	WEATHERSTRIP, RR DR OUT LH	1	Rp280.500
9	84503M68P00-000	GLASS, RR DR WINDOW RH	1	Rp518.500
10	84504M68P00-000	GLASS, RR DR WINDOW LH	1	Rp518.500
11	81770M68P00-000	SASH, RR DR RR RH	1	Rp62.500
12	81780M68P00-000	SASH, RR DR RR LH	1	Rp62.500
13	09122-76003-000	SCREW (6X16)	4	Rp15.000
14	02162-0612A-000	SCREW	2	Rp11.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
