FIG.718A REAR BUMPER

FIG.718A REAR BUMPER

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	71811M68P40-799	BUMPER, RR UPR (BLACK/PRI3Y)	1	Rp2.120.500	PAINT TO MATCH
2	71813M68P40-ZSC	BUMPER, RR LWR (GRAY)	1	Rp1.631.500
3	09132M05063-000	.SCREW (5X16)	4	Rp5.500
4	09148M05071-000	.NUT	2	Rp6.000
5	09409M07346-000	.CLIP	2	Rp5.500
6	71821M68P00-000	HOLDER, RR BUMPER SIDE RH	1	Rp38.000
7	71822M68P00-000	HOLDER, RR BUMPER SIDE LH	1	Rp38.000
8	77191-79F00-000 SUB: 77191B79F00N000	FILM	2	Rp7.500
9	09132M05063-000	SCREW (5X16)	2	Rp5.500
10	09136-05068-000	SCREW (5X20)	2	Rp15.000
11	09148-06022-000	NUT	2	Rp27.000
12	09409M07346-000	CLIP	2	Rp5.500
13	09409M08006-000	CLIP	3	Rp5.000
14	01551-0616C-000	BOLT	2	Rp14.500
15	01551-0616C-000	BOLT	1	Rp14.500
16	03541-0512B-000 SUB: 03541B0512BN000	SCREW	4	Rp4.000
17	03541-0512B-000 SUB: 03541B0512BN000	SCREW	7	Rp4.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
