FIG.745A INTERIOR TRIM

No	No. Part	Description	Qty	Price Per Pcs
1	76110M68P00-6GS	TRIM, FRONT PILLAR RH (GRAY)	1	Rp55.500
2	09409-10313-000	.CLIP	1	Rp14.000
3	09409M10321-000	.CLIP	2	Rp5.000
4	76120M68P00-6GS	TRIM, FRONT PILLAR LH (GRAY)	1	Rp55.500
5	09409-10313-000	.CLIP	1	Rp14.000
6	09409M10321-000	.CLIP	2	Rp5.000
7	76130M68P11-5PK	TRIM, DASH SIDE RH (BLACK)	1	Rp54.000
8	09409M10321-000	.CLIP	1	Rp5.000
9	76140M68P11-5PK	TRIM, DASH SIDE LH (BLACK)	1	Rp54.000
10	09409M10321-000	.CLIP	1	Rp5.000
11	76151M68P01-5PK	SCUFF, SIDE SILL FRONT RH (BLACK)	1	Rp38.000
12	76158M74L00-000	CLAMP, SIDE SILL SCUFF	10	Rp6.000
13	76161M68P01-5PK	SCUFF, SIDE SILL FRONT LH (BLACK)	1	Rp38.000
14	76170M68P00-5PK	SCUFF, SIDE SILL REAR RH (BLACK)	1	Rp57.000
15	09409M10321-000	.CLIP	1	Rp5.000
16	76180M68P00-5PK	SCUFF, SIDE SILL REAR LH (BLACK)	1	Rp57.000
17	09409M10321-000	.CLIP	1	Rp5.000
18	76190M68P10-5PK	TRIM, TAIL END (BLACK)	1	Rp238.500
19	76210M68P10-6GS	TRIM, CTR PILLAR UPPER RH (GRAY)	1	Rp62.500
20	76220M68P10-6GS	TRIM, CTR PILLAR UPPER LH (GRAY)	1	Rp62.500
21	76231M68P00-5PK	TRIM, CTR PILLAR LOWER RH (BLACK)	1	Rp135.500
22	76241M68P00-5PK	TRIM, CTR PILLAR LOWER LH (BLACK)	1	Rp135.500
23	76250M68P01-6GS	TRIM, QUARTER UPPER RH (GRAY)	1	Rp127.000
24	09409M10321-000	.CLIP	6	Rp5.000
25	76260M68P01-6GS	TRIM, QUARTER UPPER LH (GRAY)	1	Rp127.000
26	09409M10321-000	.CLIP	6	Rp5.000
27	76270M68P10-5PK	TRIM, QUARTER LOWER RH (BLACK)	1	Rp500.000
28	76272M68P00-5PK	.CAP, QUARTER LOWER TRIM (BLACK)	1	Rp10.500
29	09409M10321-000	.CLIP	3	Rp5.000
30	76280M68P10-5PK	TRIM, QUARTER LOWER LH (BLACK)	1	Rp500.000
31	76272M68P00-5PK	.CAP, QUARTER LOWER TRIM (BLACK)	1	Rp10.500
32	09409M10321-000	.CLIP	3	Rp5.000
33	76291M68P00-000	TRIM, FR DR OPENING	2	Rp305.500
34	76295M68P01-000	TRIM, RR DR OPENING	2	Rp357.500
35	09409M07L02-5PK	CLIP (BLACK)	2	Rp7.500
36	76410M79M20-6GS SUB: 76410M79M02-6GS	GRIP, ASSISTANT (GRAY)	2	Rp82.500
37	76410M79M12-6GS	GRIP, ASSISTANT (GRAY)	1	Rp81.000
