FIG.590A FRONT BODY PANEL

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	58310M68P10-000	PANEL, FENDER 4ON RH	1	Rp995.000
2	58315M68P00-000	EXTENSION, FR FNDR LWR BRKT RH	1	Rp23.000
3	58316M68P00-000	BRACKET, FR FENDER UPR FR RH	1	Rp16.500
4	58322M68P00-000	BRACKET, FR FENDER LWR RH	1	Rp11.500
5	58410M68P10-000	PANEL, FENDER 4ON LH	1	Rp995.000
6	58415M68P00-000	EXTENSION, FR FNDR LWR BRKT LH	1	Rp23.000
7	58416M68P00-000	BRACKET, FR FENDER UPR FR LH	1	Rp16.500
8	58422M68P00-000	BRACKET, FR FENDER LWR LH	1	Rp11.500
9	58600M68P10-000 SUB: 58600M68P11-000	MEMBER, FR SIDE RH	1	Rp5.194.000
10	58610M68P10-000	.MEMBER, 4ON SIDE RH	1	Rp2.109.500
11	58614M68P10-000	..BRACE, LAMP SUPPORT RH	1	Rp113.500
12	58615M68P00-000	..PLATE, 4ON SIDE MEMBER FR RH	1	Rp73.000
13	58616M68P00-000	..EXTENSION, 4ON SIDE MBR INS RH	1	Rp62.500
14	58618M68P10-000	..BRACE, RDTR SPRT INR RH	1	Rp32.500
15	58619M68P00-000	..EXTENSION, 4ON SIDE MBR OUT RH	1	Rp48.000
16	58665M68P00-000	..BRACKET, FR BUMPER MEMBER	1	Rp20.500
17	58666M68P00-000	..GUSSET, LAMP SUPPORT BRACE RH	1	Rp29.000
18	58667M68P00-000	..REINF, LAMP SUPPORT BRACE RH	1	Rp23.000
19	58620M68P10-000	.MEMBER, DASH LWR RH	1	Rp87.500
20	58628M68P10-000	.REINF, 4N SIDE MBR RR RH	1	Rp81.000
21	58630M68P30-000	.MEMBER, 4ON SIDE OUTER RH	1	Rp1.493.500
22	58625M68P10-000	EXTENSION, DASH LWR INR RH	1	Rp57.500
23	58640M68P00-000	EXTENSION, DASH LWR OTR RH	1	Rp525.000
24	58650M68P00-000	CROSSMEMBER, DASH UPR RH	1	Rp65.000
25	58700M68P21-000	MEMBER, FR SIDE LH	1	Rp5.080.000
26	58710M68P10-000	.MEMBER, 4ON SIDE LH	1	Rp2.109.500
27	58665M68P00-000	..BRACKET, FR BUMPER MEMBER	1	Rp20.500
28	58714M68P10-000	..BRACE, LAMP SUPPORT LH	1	Rp113.500
29	58715M68P00-000	..PLATE, 4ON SIDE MEMBER FR LH	1	Rp73.000
30	58716M68P00-000	..EXTENSION, 4ON SIDE MBR INS LH	1	Rp64.500
31	58718M68P10-000	..BRACE, RDTR SPRT INR LH	1	Rp32.500
32	58719M68P00-000	..EXTENSION, 4ON SIDE MBR OUT LH	1	Rp48.000
33	58762M68P00-000	..REINF, TOWING HOOK NUT FR	1	Rp18.500
34	58763M68P00-000	..NUT, TOWING HOOK	1	Rp151.000
35	58766M68P00-000	..GUSSET, LAMP SUPPORT BRACE LH	1	Rp29.000
36	58767M68P00-000	..REINF, LAMP SUPPORT BRACE LH	1	Rp23.000
37	58720M54T00-000	.MEMBER, DASH LWR LH	1	Rp33.500
38	58728M68P10-000	.REINF, 4N SIDE MBR RR LH	1	Rp81.000
39	58730M68P30-000	.MEMBER, 4ON SIDE OUTER LH	1	Rp1.493.500
40	58725M68P10-000	EXTENSION, DASH LWR INR LH	1	Rp87.500
41	58740M68P00-000	EXTENSION, DASH LWR OTR LH	1	Rp530.000
42	58750M68P00-000	CROSSMEMBER, DASH UPR LH	1	Rp65.000
43-1	59100M68PA1-000	PANEL, DASH	1	Rp1.848.500	5MT
43-2	59100M68PE1-000	PANEL, DASH	1	Rp1.810.000	4AT
44	59221M68P20-000	CROSSMEMBER, DASH UPR CTR	1	Rp61.500
45	59230M50S00-000	PANEL, DASH SIDE RH	1	Rp597.500
46	59232M68P10-000	PANEL, DASH SIDE FR RH	1	Rp165.000
47	59233M68P00-000	BRACKET, FR FENDER RH	2	Rp8.500
48	59236M68P00-000	PATCH, FR HOOD HINGE RH	1	Rp11.500
49	59280M50S00-000	PANEL, DASH SIDE LH	1	Rp842.000
50	59282M68P10-000	PANEL, DASH SIDE FR LH	1	Rp165.000
51	59286M68P00-000	PATCH, FR HOOD HINGE LH	1	Rp11.500
52	DISCONTINUE SUB: 01550B0612AN000	BOLT	2	-
53	59300M50S40-000	PANEL, COWL UPR	1	Rp712.000
54	59411M68P10-000	MEMBER, COWL SIDE OUTER RH	1	Rp239.000
55	59461M68P10-000	MEMBER, COWL SIDE OUTER LH	1	Rp239.000
56	01550-0820A-000 SUB: 01550B0820AN000	BOLT	6	Rp5.500
57	59710M68P10-000	PANEL, COWL TOP	1	Rp336.500
