FIG.850A REAR SEAT

No	No. Part	Description	Qty	Price Per Pcs
1	86401M68P10-PWC	HEADRESTRAINT ASSY, RR (BLACK)	2	Rp355.500
2	86401M68P20-PWC	HEADRESTRAINT ASSY, RR CTR (BLACK)	1	Rp237.500
3	87160M68PA1-000	PAD, RR CUSH	1	Rp1.556.000
4	87180M68PA0-EEV	TRIM, RR CUSH (BLUE/BLACK)	1	Rp649.000
5	09387-19001-000	RING (OD:22.6)	37	Rp9.000
6	85341M79M10-5PK	GUIDE, HEADRESTRAINT (BLACK)	1	Rp9.500
7	85840M79M20-5PK	GUIDE, HEADRESTRAINT (BLACK)	1	Rp11.000
8	87225M68P00-5PK	COVER, TETHER ANCHOR (BLACK)	1	Rp20.500
9	87310M68PG0-000	FRAME, RR BACK RH	1	Rp733.500
10	87360M68PG0-000	PAD, RR BACK RH	1	Rp260.500
11	87480M83P00-000	LOCK ASSY, RR BACK	1	Rp470.500
12	87293-54G00-000	PIN, REAR BACK KNOB	1	Rp50.000
13	87483-80J11-5PK	KNOB, RR BACK LOCK (BLACK)	1	Rp86.500
14	87484-80J11-000	CASE, RR BACK LOCK	1	Rp177.000
15	87485M68PA0-000	WIRE, RR BACK LOCK RH	1	Rp10.500
16	87486M68P00-000	SPRING, RR BACK KNOB	1	Rp11.500
17	01550-0835A-000	BOLT	2	Rp3.500
18	87341M68P00-000	PAD, RR BACK HINGE	1	Rp25.000
19	87380M68PG0-EEV	TRIM, RR BACK RH (BLUE/BLACK)	1	Rp886.000
20	87482M68P00-5PK	BEZEL, RR BACK LOCK RH (BLACK)	1	Rp24.000
21	09387-19001-000	RING (OD:22.6)	3	Rp9.000
22	85341M79M10-5PK	GUIDE, HEADRESTRAINT (BLACK)	2	Rp9.500
23	85840M79M20-5PK	GUIDE, HEADRESTRAINT (BLACK)	2	Rp11.000
24	87225M68P00-5PK	COVER, TETHER ANCHOR (BLACK)	1	Rp20.500
25	87227M68PA0-5PK	COVER, SHOULDER ANCHOR (BLACK)	1	Rp42.000
26	87321M68PA0-000	COVER, SHOULDER ANCHOR INNER	1	Rp44.000
27	87810M68PG0-000	FRAME, RR BACK LH	1	Rp1.445.500
28	87860M68PG0-000	PAD, RR BACK LH	1	Rp433.000
29	87980M83P00-000	LOCK ASSY, RR BACK	1	Rp470.500
30	87293-54G00-000	PIN, REAR BACK KNOB	1	Rp50.000
31	87483-80J11-5PK	KNOB, RR BACK LOCK (BLACK)	1	Rp86.500
32	87484-80J11-000	CASE, RR BACK LOCK	1	Rp177.000
33	87486M68P00-000	SPRING, RR BACK KNOB	1	Rp11.500
34	87985M68PA0-000	WIRE, RR BACK LOCK LH	1	Rp10.500
35	01550-0835A-000	BOLT	2	Rp3.500
36	87342M68PA0-000	PAD, RR BACK HINGE	1	Rp15.000
37	87880M68PG0-EEV	TRIM, RR BACK (BLUE/BLACK)	1	Rp886.000
38	87982M68P00-5PK	BEZEL, RR BACK LOCK LH (BLACK)	1	Rp24.000
39	09387-19001-000	RING (OD:22.6)	3	Rp9.000
40	87228M68P00-5PK	BEZEL, LOWER ANCHOR (BLACK)	4	Rp17.500
41	87460-76G11-000 SUB: 87460-76G10-000	HOOK, RR SEAT CUSH	2	Rp39.000
42	87491M68P10-5PK	COVER, RR SEAT HINGE RH (BLACK)	1	Rp10.000
43	87911M68P00-000	BRACKET, RR HINGE	1	Rp24.000
44	87950M68P00-000	HINGE, RR CTR	1	Rp138.000
45	87991M68P10-5PK	COVER, RR SEAT HINGE LH (BLACK)	1	Rp10.000
46	DISCONTINUE SUB: 01550B0612AN000	BOLT	1	-
47	01551-1025A-000	BOLT	2	Rp29.000
