FIG.732A HEATER UNIT

No	No. Part	Description	Qty	Price Per Pcs
1	74100M51S60-000	HVAC UNIT	1	Rp6.990.000
2	74110M68P40-000	.CASE, HEATER	1	Rp447.000
3	74113M68P00-000	..DUCT, AIR	1	Rp15.000
4	74116M68P20-000	..PACKING	1	Rp37.000
5	74171M68P00-000	..DOOR ASSY	1	Rp44.000
6	74172M68P00-000	..DOOR ASSY	1	Rp61.500
7	74173M68P00-000	..DOOR ASSY	1	Rp49.500
8	74178M79M00-000	..DOOR, A/M	1	Rp187.500
9	74191M68P00-000	..LEVER	1	Rp6.500
10	74193M68P00-000	..LEVER	1	Rp10.500
11	74194M68P00-000	..LEVER	1	Rp6.500
12	74197M68P00-000	..SHAFT	1	Rp10.500
13	74114M68P20-000	.DUCT ASSY, AIR	1	Rp19.500
14	74115M68P20-000	.DUCT ASSY, AIR	1	Rp22.500
15	74117M79M00-000	.PACKING	1	Rp41.000
16	74120M68P20-000	.CORE ASSY, HTR	1	Rp1.026.000
17	74120M82P10-000	.PACKING	1	Rp74.000
18	74121M68P00-000	.INSULATOR	1	Rp7.500
19	74131M68P00-000	.COVER	1	Rp18.500
20	74134-58J00-000 SUB: 74134B58J00N000	.BOLT	2	Rp14.000
21	74135-82000-000	.SCREW, MOTOR	3	Rp19.500
22	74150M68P31-000 SUB: 74150M68P21-000	.MOTOR ASSY, W/FAN	1	Rp1.188.500
23	74161M68P00-000	.PACKING	1	Rp110.000
24	74162M68P00-000	.PACKING	1	Rp74.000
25	74163M68P00-000	.PACKING	1	Rp61.500
26	74164M68P00-000	.PACKING	2	Rp15.000
27	74165M68P00-000	.PACKING	2	Rp11.000
28	74181M68P90-000	.LEVER, PLATE	1	Rp13.000
29	74196M68P90-000	.ROD	1	Rp11.500
30	74210M68P90-000	.CASE, BLOWER	1	Rp281.000
31	74119M68P20-000	..BUSH	1	Rp27.000
32	74119-78F10-000 SUB: 74119B78F10N000	..BUSH	2	Rp8.000
33	74119M79M00-000	..BOLT	2	Rp9.000
34	74176M68P00-000	..DOOR ASSY	1	Rp54.500
35	74281M68P90-000	..LEVER	1	Rp15.000
36	74214M68P00-000	.HOLDER, FILTER	1	Rp18.500
37	74220M50S50-000	.CASE, BLOWER	1	Rp130.000
38	74118-63J01-000	..PACKING, HTR PIPE	1	Rp74.000
39	74119-78F10-000 SUB: 74119B78F10N000	..BUSH	1	Rp8.000
40	74119M79M00-000	..BOLT	1	Rp9.000
41	74221M68P00-000	..BRACKET	1	Rp17.000
42	74222M68P00-000	..BRACKET	1	Rp19.500
43	74226M68P00-000	.BRACKET	1	Rp33.000
44	95411M68P21-000	.EVAPORATOR ASSY	1	Rp794.500
45	95431M50S20-000	.VALVE, EXPANSION	1	Rp574.500
46	95541M68P20-000	.THERMISTOR ASSY	1	Rp255.500
47	95626M79M00-000	.POWER TRANSISTOR ASSY, BLO	1	Rp743.000
48	95653M68P90-000	.SERVO MOTOR ASSY, W/ACC	1	Rp526.500
49	95654M68P90-000	.SERVO MOTOR ASSY, W/ACC	1	Rp481.500
50	95655M68P90-000	.SERVO & ACC ASSY	1	Rp508.500
51	95850M55R00-000	.FILTER ASSY	1	Rp159.000
52	03112-0416A-000	.SCREW	24	Rp23.500
53	95481M68P01-000	HOSE, DRAIN	1	Rp57.000
54	09122-76003-000	SCREW (6X16)	1	Rp15.000
55	09159-06086-000	NUT	3	Rp26.500
56	08361M2506A-000	NUT	1	Rp7.000
