NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.570A FRONT HOOD PANELFIG.580A FRONT FENDER PANELFIG.590A FRONT BODY PANELFIG.600A FLOOR PANELFIG.640A SIDE BODY PANELFIG.660A ROOF PANELFIG.717A FRONT BUMPERFIG.718A REAR BUMPERFIG.720A INSTRUMENT PANELFIG.730A VENTILATORFIG.732A HEATER UNITFIG.740A CONSOLE BOXFIG.73AA HEATER CONTROLFIG.741A FLOOR CARPETFIG.745A INTERIOR TRIMFIG.750A COVER/CAPFIG.755A FUEL LID OPENERFIG.757A ROOF SIDE PADFIG.760A ROOF LININGFIG.772A MOLDINGFIG.774A SPLASH GUARDFIG.780A EMBLEMFIG.790A WINDSHIELDFIG.800A FRONT DOOR PANELFIG.801A REAR DOOR PANELFIG.805A BACK DOOR PANELFIG.810A FRONT DOOR REGULATORFIG.811A REAR DOOR REGULATORFIG.820A FRONT DOOR LOCKFIG.821A REAR DOOR LOCKFIG.824A BACK DOOR LOCKFIG.835A MIRROR/SUNVISORFIG.840A SEAT BELTFIG.848A FRONT LH SEATFIG.849A FRONT RH SEATFIG.850A REAR SEATFIG.860A PARCEL SHELFFIG.865A FUEL TANKFIG.893A TOOLFIG.952A AIR CONDITIONERFIG.990A COMPRESSOR

FIG.570A FRONT HOOD PANEL

FIG.570A FRONT HOOD PANEL
No No. Part Description Qty Price Per Pcs Remarks
1 57300M68P10-000 PANEL, FR HOOD 1 Rp1.736.500
2 57410M68P00-000 HINGE, FR HOOD RH 1 Rp110.500
3 57420M68P00-000 HINGE, FR HOOD LH 1 Rp110.500
4 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 4 -
5 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 4 -
6 58230M50S30-000 MEMBER, HOOD LOCK 1 Rp331.000
7 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 8 -
8 58270M68P10-000 MEMBER, FR BUMPER 1 Rp522.000
9 01550-0820A-000
SUB: 01550B0820AN000		 BOLT 6 Rp5.500
10 72311M68P01-000 STAY, FR HOOD 1 Rp21.500
11 72312M68K00-000 HOLDER, FR HOOD STAY 1 Rp5.500
12 72330M68P00-5PK GARNISH, COWL TOP (BLACK) 1 Rp419.500
13 72361M68P01-000 SEAL, HOOD FR 1 Rp34.500
14 72370M68P00-000 SEAL, HOOD RR 1 Rp54.500
15 72371M68P00-5PK GARNISH, COWL TOP SIDE RH (BLACK) 1 Rp14.500
16 72372M68P00-5PK GARNISH, COWL TOP SIDE LH (BLACK) 1 Rp14.500
17 72372M70F10-000 CUSHION 2 Rp6.000
18 72380M68P00-000 PANEL, FR COWL UPR 1 Rp547.000
19 72390M68P00-000 CROSSMEMBER, FR LWR 1 Rp641.500
20 72481M50S00-000 PAD, FRONT BUMPER 2 Rp7.000
21 09209M09L02-000 LINKAGE 1 Rp4.500
22 09321-10023-000
SUB: 09321B10023N000		 CUSHION (HD:10) 1 Rp6.000
23 09409-10304-000 CLIP 8 Rp5.000
24 09409M07L02-5PK CLIP (BLACK) 5 Rp7.500
25 02162-0612A-000 SCREW 1 Rp11.000
26 02162-0616A-000 SCREW 4 Rp3.000
27 08316-1006A-000 NUT 4 Rp2.000
28 72440M68P00-000 SILENCER, FR HOOD 1 Rp219.500
29 09409M07346-000 CLIP 11 Rp5.500
30 82110M68P20-000 LATCH, HOOD 1 Rp183.000
31 82160M50S00-000 CABLE, HOOD LATCH RELEASE 1 Rp62.500
32 02162-0616A-000 SCREW 3 Rp3.000
33 76238M70F00-000 CLAMP, CABLE 4 Rp5.000
34 72351-81P00-000 GUIDE, COWL DRAIN 2 Rp140.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
