FIG.801A REAR DOOR PANEL

No	No. Part	Description	Qty	Price Per Pcs
1	68003M68P03-000 SUB: 68003M68P01-000	PANEL ASSY, RR DR RH	1	Rp3.183.000
2	68004M68P03-000 SUB: 68004M68P01-000	PANEL ASSY, RR DR LH	1	Rp3.183.000
3	69410-68L00-000 SUB: 69410B68L00N000	HINGE, RR DR UPR RH	1	Rp75.500
4	69420-68L00-000 SUB: 69420B68L00N000	HINGE, RR DR UPR LH	1	Rp77.000
5	69430-68L00-000	HINGE, RR DR LWR RH	1	Rp474.000
6	69440-68L00-000	HINGE, RR DR LWR LH	1	Rp419.500
7	08361-2508A-000	NUT	4	Rp16.500
8	09159M08151-000	NUT	4	Rp11.500
9	09103M08557-000	BOLT (8X24)	8	Rp8.500
10	81830M75L01-000	STOP, DR OPEN	2	Rp89.500
11	09103-06248-000	BOLT (6X20)	4	Rp23.500
12	09112-08015-000	BOLT (8X25)	2	Rp32.000
13	83703M68PC1-DUZ	TRIM ASSY, REAR DOOR RH (BLUE/BLACK)	1	Rp948.500
14	83752M55K00-5PK	.CAP, SIDE DOOR INSIDE PULL CASE (BLACK)	1	Rp9.500
15	09409M10321-000	.CLIP	7	Rp5.000
16	83704M68PC1-DUZ	TRIM ASSY, REAR DOOR LH (BLUE/BLACK)	1	Rp948.500
17	83752M55K00-5PK	.CAP, SIDE DOOR INSIDE PULL CASE (BLACK)	1	Rp9.500
18	09409M10321-000	.CLIP	7	Rp5.000
19	83755-74L00-5PK	CAP, SIDE DR INSIDE HDL BEZEL RH (BLACK)	1	Rp24.000
20	83756-74L00-5PK	CAP, SIDE DR INSIDE HDL BEZEL LH (BLACK)	1	Rp24.000
21	83913M68P00-000	COVER, RR DR SEALING	2	Rp13.500
22	83751M75J00-000	BRACKET, DR TRIM RH	1	Rp4.000
23	83756M75J00-000	BRACKET, DR TRIM LH	1	Rp4.000
24	03141M0612A-000	SCREW	2	Rp4.500
25	71851M70F00-000	NUT	2	Rp4.000
26	09132-05058-000	SCREW (5X12)	2	Rp14.000
27	09409-06314-5PK	CLIP (5.9X20.5) (BLACK)	2	Rp3.500
28	82711-65J00-000	CUSHION	2	Rp34.000
29	83871M68P00-000	WEATHERSTRIP, RR DR INNER RH	1	Rp94.000
30	83881M68P00-000	WEATHERSTRIP, RR DR INNER LH	1	Rp94.000
31	84661M68P10-000	WEATHERSTRIP, RR DR OPNG RH	1	Rp268.500
32	84671M68P10-000	WEATHERSTRIP, RR DR OPNG LH	1	Rp268.500
33	83925M50S00-0CB	TAPE, REAR DOOR OUTER ROOF RH (BLACK)	1	Rp31.500
34	83926M50S00-0CB	TAPE, REAR DOOR OUTER ROOF LH (BLACK)	1	Rp31.500
35	83927M50S00-0CB	TAPE, REAR DOOR OUTER FR RH (BLACK)	1	Rp48.500
36	83928M50S00-0CB	TAPE, REAR DOOR OUTER FR LH (BLACK)	1	Rp48.500
37	83931M50S00-0CB	TAPE, REAR DOOR OUTER RR RH (BLACK)	1	Rp54.000
38	83932M50S00-0CB	TAPE, REAR DOOR OUTER RR LH (BLACK)	1	Rp54.000
39	77191-79F00-000 SUB: 77191B79F00N000	FILM	2	Rp7.500
