FIG.848A FRONT LH SEAT

FIG.848A FRONT LH SEAT
No No. Part Description Qty Price Per Pcs Remarks
1 85160M68PA0-000 PAD, FR CUSH 1 Rp447.000
2 85603M68PC1-000 FRAME ASSY, FR CUSH LH 1 Rp1.633.000
3 86652M74P50-000 .CAP, FR ADJUSTER LOWER 2 Rp5.500
4 86653M74P50-000 .CAP, FR ADJUSTER UPPER 1 Rp5.500
5 86657-68P00-000 .PROTECTOR, FR ADJUSTER REAR 1 Rp10.000
6 86658-68P00-000 .RING, FR ADJUSTER REAR 1 Rp6.500
7 86652M74P50-000 .CAP, FR ADJUSTER LOWER 2 Rp5.500
8 86653M74P50-000 .CAP, FR ADJUSTER UPPER 1 Rp5.500
9 86657-68P00-000 .PROTECTOR, FR ADJUSTER REAR 1 Rp10.000
10 86658-68P00-000 .RING, FR ADJUSTER REAR 1 Rp6.500
11 85680M50S00-EEU TRIM, FR CUSH LH (BLUE/BLACK) 1 Rp343.500
12 09387-19001-000 RING (OD:22.6) 10 Rp9.000
13 85222-68P00-5PK COVER, FR RCLNG INSIDE LOWER RH (BLACK) 1 Rp10.500
14 85242-68P00-5PK COVER, FR RCLNG INSIDE LOWER LH (BLACK) 1 Rp10.500
15 85306M50SJ0-000 BACK ASSY, FR LH 1 Rp2.871.000
16 85341M68P00-5PK GUIDE, HEADRESTRAINT (BLACK) 1 Rp15.000
17 85840M68P00-5PK GUIDE, HEADRESTRAINT (BLACK) 1 Rp31.000
18 85880M68PK0-EEU TRIM, FR BACK LH (BLUE/BLACK) 1 Rp592.500
19 09387-19001-000 RING (OD:22.6) 11 Rp9.000
20 85711-62R00-5PK KNOB, RCLNG LH (BLACK) 1 Rp86.000
21 85720M52R00-5PK COVER, FR RCLNG OUTSIDE LH (BLACK) 1 Rp34.000
22 85249M68P00-000 .CLIP 1 Rp9.500
23 85740M68P30-5PK COVER, FR RCLNG INSIDE LH (BLACK) 1 Rp27.000
24 85249M68P00-000 .CLIP 1 Rp9.500
25 86401M68P00-PWC HEADRESTRAINT ASSY, FR (BLACK) 1 Rp437.000
26 09132M04038-000 SCREW (4X10) 1 Rp5.500
27 01550-1016A-000
SUB: 01550B1016AN000		 BOLT 4 Rp5.500
28 03541-0410A-000 SCREW 2 Rp11.000
29 09119M08118-000
SUB: 09119M08111-000		 BOLT (8X25) 4 Rp6.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
