FIG.820A FRONT DOOR LOCK

FIG.820A FRONT DOOR LOCK
No No. Part Description Qty Price Per Pcs Remarks
1 82271M68850-000 CYLINDER SET, FR DR LATCH RH 1 Rp287.000
2 82201M68P43-000
SUB: 82201M68P42-000		 LATCH ASSY, FR DR RH 1 Rp665.000
3 82202M68P54-000
SUB: 82202M68P53-000		 LATCH ASSY, FR DR LH 1 Rp445.500
4 09137-06032-000 SCREW (6X18) 6 Rp16.500
5 82610M76M01-000 STRIKER, DR LATCH 2 Rp27.000
6 09137-08014-000 SCREW (8X18) 4 Rp23.000
7 82810M68812-0PG
SUB: 82810M68810-0PG		 HANDLE SET, FR DR OUT RH (CHROME) 1 Rp786.000
8 82812M68P00-000 .BRACKET, FR DR OUT HANDLE RH 1 Rp13.000
9 82813M68P00-000 .PAD, FR DR OUT HANDLE 1 Rp4.500
10 82820M68821-0PG
SUB: 82820M68820-0PG		 HANDLE SET, FR DR OUT LH (CHROME) 1 Rp786.000
11 82822M68P00-000 .BRACKET, FR DR OUT HANDLE LH 1 Rp13.000
12 82813M68P00-000 .PAD, FR DR OUT HANDLE 1 Rp4.500
13 09116-06168-000 BOLT (6X12) 4 Rp15.000
14 09250M25L02-000 CAP (OD:33.5) 2 Rp5.500
15 83110M74L10-C48 HANDLE, SIDE DOOR INSIDE RH (CHROME/BLACK) 1 Rp111.000
16 83130M74L10-C48 HANDLE, SIDE DOOR INSIDE LH (CHROME/BLACK) 1 Rp111.000
17 83119M75J00-000 NUT, SIDE DOOR INSIDE HANDLE 2 Rp5.500
18 83271M66R00-000 CLIP, DR HANDLE ROD 2 Rp6.500
19 83759M53M00-000 PAD 6 Rp5.500
20 09132-05058-000 SCREW (5X12) 2 Rp14.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
