FIG.849A FRONT RH SEAT

No	No. Part	Description	Qty	Price Per Pcs
1	85103M68PB4-000	FRAME ASSY, FR CUSH RH	1	Rp2.946.000
2	86652M74P50-000	.CAP, FR ADJUSTER LOWER	2	Rp5.500
3	86653M74P50-000	.CAP, FR ADJUSTER UPPER	1	Rp5.500
4	86657-68P00-000	.PROTECTOR, FR ADJUSTER REAR	1	Rp10.000
5	86658-68P00-000	.RING, FR ADJUSTER REAR	1	Rp6.500
6	86652M74P50-000	.CAP, FR ADJUSTER LOWER	2	Rp5.500
7	86653M74P50-000	.CAP, FR ADJUSTER UPPER	1	Rp5.500
8	86657-68P00-000	.PROTECTOR, FR ADJUSTER REAR	1	Rp10.000
9	86658-68P00-000	.RING, FR ADJUSTER REAR	1	Rp6.500
10	85160M68PA0-000	PAD, FR CUSH	1	Rp447.000
11	85180M50S20-EEU	TRIM, FR CUSH RH (BLUE/BLACK)	1	Rp343.500
12	09387-19001-000	RING (OD:22.6)	10	Rp9.000
13	85191M74L00-000	CLAMP	1	Rp9.000
14	85211-62R00-5PK	KNOB, RCLNG RH (BLACK)	1	Rp83.500
15	85213-62R20-5PK	LEVER, SEAT LIFTER RH (BLACK)	1	Rp46.500
16	85214M68PB0-5PK	CAP, LIFTER LEVER (BLACK)	1	Rp11.500
17	85221M62R20-5PK	COVER, FR RCLNG OUTSIDE RH (BLACK)	1	Rp23.500
18	85222-68P00-5PK	COVER, FR RCLNG INSIDE LOWER (BLACK)	1	Rp10.500
19	85240M68P30-5PK	COVER, FR RCLNG INSIDE RH (BLACK)	1	Rp27.000
20	85249M68P00-000	.CLIP	1	Rp9.500
21	85242-68P00-5PK	COVER, FR RCLNG INSIDE LOWER LH (BLACK)	1	Rp10.500
22	85244M68P20-5PK	COVER, RISER OUTSIDE RH (BLACK)	1	Rp33.500
23	85305M50SJ0-000	BACK ASSY, FR RH	1	Rp2.846.000
24	85341M68P00-5PK	GUIDE, HEADRESTRAINT (BLACK)	1	Rp15.000
25	85380M68PJ0-EEU	TRIM, FR BACK RH (BLUE/BLACK)	1	Rp592.500
26	85840M68P00-5PK	GUIDE, HEADRESTRAINT (BLACK)	1	Rp31.000
27	09387-19001-000	RING (OD:22.6)	11	Rp9.000
28	86401M68P00-PWC	HEADRESTRAINT ASSY, FR (BLACK)	1	Rp437.000
29	09132M04038-000	SCREW (4X10)	1	Rp5.500
30	09132M05065-000	SCREW (5X10)	2	Rp5.500
31	36990-25G00-000	CLAMP (L:125)	1	Rp13.000
32	09407M14414-000	CLAMP (L:140)	1	Rp6.500
33	01550-1016A-000 SUB: 01550B1016AN000	BOLT	4	Rp5.500
34	03541-0410A-000	SCREW	2	Rp11.000
35	09119M08118-000 SUB: 09119M08111-000	BOLT (8X25)	4	Rp6.500
