| 1 |
51358-09G00-000
SUB: 51358B09G00N000 |
STOPPER, HANDLEBAR |
1 |
Rp8.000 |
| |
| 2 |
56110-09J00-000
SUB: 56110B09J00N000 |
HANDLEBAR |
1 |
Rp153.000 |
| |
| 3 |
56311-09J00-888
SUB: 56311B09J00N888 |
COVER, HANDLE FRONT |
1 |
Rp57.000 |
| |
| 4 |
56321-09J20-291
SUB: 56321B09J00N291 |
COVER, HANDLE REAR |
1 |
Rp31.500 |
| |
| 5 |
68281-13HA0-ADM
SUB: 68281B13HA0NADM |
EMBLEM, " S " |
1 |
Rp9.500 |
| |
| 6 |
68281-09J00-BYC
SUB: 68281B09J00N000 |
EMBLEM, " FI " |
1 |
Rp9.500 |
| |
| 7 |
09103-10126-000
SUB: 09103B10126N000 |
BOLT (10X48) |
1 |
Rp28.500 |
| |
| 8 |
09148-04019-000
SUB: 09148B04019N000 |
NUT |
2 |
Rp6.500 |
| |
| 9 |
02142-0512B-000
SUB: 02142B0512BN000 |
SCREW |
1 |
Rp5.500 |
| |
| 10 |
03541-0416B-000
SUB: 03541B0416BN000 |
SCREW |
2 |
Rp4.500 |
| |
| 11 |
03541-0416B-000
SUB: 03541B0416BN000 |
SCREW |
2 |
Rp4.500 |
| |
| 12 |
03541-0516A-000
SUB: 03541B0516AN000 |
SCREW |
2 |
Rp3.500 |
| |
| 13 |
08319-3110A-000
SUB: 08319B3110AN000 |
NUT |
1 |
Rp4.500 |
| |
| 14 |
56500-09J12-000
SUB: 56500B09J10N000 |
MIRROR ASSY, REAR VIEW RH |
1 |
Rp82.000 |
| |
| 15 |
56600-09J12-000
SUB: 56600B09J10N000 |
MIRROR ASSY, REAR VIEW LH |
1 |
Rp82.000 |
| |
| 16 |
58300-09J01-000
SUB: 58300B09J00N000 |
CABLE ASSY, THROTTLE |
1 |
Rp116.000 |
| |
| 17 |
58510-09J10-000
SUB: 58510B09J10N000 |
CABLE, REAR BRAKE |
1 |
Rp79.500 |
| |
| 18 |
58562-09J00-000
SUB: 58562B09J00N000 |
SPRING, REAR BRAKE CABLE |
1 |
Rp3.000 |
| |
| 19 |
58575-09J00-000
SUB: 58575B09J00N000 |
PLATE, REAR BRAKE CABLE |
1 |
Rp3.500 |
| |
| 20 |
DISCONTINUE
SUB: 58577B46G30N000 |
CLAMP, RR BK CABLE CRKC FR |
1 |
- |
| |
| 21 |
09150-06010-000
SUB: 09150B06010N000 |
NUT |
1 |
Rp4.500 |
| |
| 22 |
09209-11002-000
SUB: 09209B11002N000 |
PIN (11X18) |
1 |
Rp7.500 |
| |
| 23 |
01547-0610A-000
SUB: 01547B0610AN000 |
BOLT |
1 |
Rp3.000 |
| |
| 24 |
DISCONTINUE
SUB: 02112B0510AN000 |
SCREW |
1 |
- |
| |
| 25 |
02112-0512A-000
SUB: 02112B0512AN000 |
SCREW |
1 |
Rp2.500 |
| |
