FIG. 435A FRONT LEG SHIELD

FIG. 435A FRONT LEG SHIELD
No No. Part Description Qty Price Per Pcs Remarks
1-2 48111-49K00-YVU SHIELD, LEG FRONT (BLACK) 1 Rp202.500
1-1 48111-49K00-YUH SHIELD, LEG FRONT (WHITE) 1 Rp193.000
1-5 48111-49K00-YUA SHIELD, LEG FRONT (BLUE) 1 Rp202.500
1-4 48111-49K00-291 SHIELD, LEG FRONT (BLACK) 1 Rp202.500
1-3 48111-49K00-YZE SHIELD, LEG FRONT (RED) 1 Rp202.500
2-1 48112-49K00-YUH SHIELD, LEG SIDE, RH (WHITE) 1 Rp100.500
2-2 48112-49K00-YVU SHIELD, LEG SIDE, RH (BLACK) 1 Rp123.000
2-3 48112-49K00-YZE SHIELD, LEG SIDE, RH (RED) 1 Rp100.500
2-4 48112-49K00-291 SHIELD, LEG SIDE, RH (BLACK) 1 Rp104.500
2-5 48112-49K00-YUA SHIELD, LEG SIDE, RH (BLUE) 1 Rp100.500
3-1 48113-49K00-YUH SHIELD, LEG SIDE, LH (WHITE) 1 Rp100.500
3-2 48113-49K00-YVU SHIELD, LEG SIDE, LH (BLACK) 1 Rp123.000
3-3 48113-49K00-YZE SHIELD, LEG SIDE, LH (RED) 1 Rp100.500
3-4 48113-49K00-291 SHIELD, LEG SIDE, LH (BLACK) 1 Rp104.500
3-5 48113-49K00-YUA SHIELD, LEG SIDE, LH (BLUE) 1 Rp100.500
4 48114-49K00-000 SHIELD, LEG FRONT LOWER 1 Rp106.500
5 48115-49K00-000 COVER, HEADLAMP 1 Rp76.000
6 48150-49K00-000 BRACE, LEG SHIELD 1 Rp78.000
7 68281-22J01-ANN
SUB: 68281-22J00-ANN		 EMBLEM, FI (SILVER/GRAY) 1 Rp3.500
8-2 68182-12K00-BS4 TAPE, "SUZUKI" (GRAY/BLACK) 2 Rp5.000 FOR YVU
8-3 68182-12K00-GTA TAPE, "SUZUKI" (RED/BLACK) 2 Rp12.000 FOR YZE
8-4 68182-12K00-E9R TAPE, "SUZUKI" (GRAY/BLACK) 2 Rp10.500 FOR 291
8-5 68182-12K00-BS5 TAPE, "SUZUKI" (GRAY/BLUE) 2 Rp4.000 FOR YUA
8-1 68182-12K00-BS3 TAPE, "SUZUKI" (GRAY/WHITE) 2 Rp5.000 FOR YUH
9-1 68648-49K00-E9R TAPE, LEG FRONT UPPER(GRAY/BLACK) 2 Rp3.500 FOR 291
9-2 68648-49K00-BS5 TAPE, LEG FRONT UPPER(GRAY/BLUE) 2 Rp3.500 FOR YUA
10 09148-04019-000
SUB: 09148B04019N000		 NUT 4 Rp6.500
11 09148-04019-000
SUB: 09148B04019N000		 NUT 4 Rp6.500
12 09148-04019-000
SUB: 09148B04019N000		 NUT 2 Rp6.500
13 09409-06314-5PK CLIP 2 Rp3.500
14 01550-0612A-000 BOLT 2 Rp3.500
15 03541-0416A-000 SCREW 2 Rp3.500
16 03541-0416A-000 SCREW 2 Rp3.500
17 03541-0416A-000 SCREW 5 Rp3.500
18 03541-0416B-000
SUB: 03541B0416BN000		 SCREW 4 Rp4.500
19 48190-09J00-000
SUB: 48190B09J00N000		 PLATE, FRONT LICENSE 1 Rp21.000
20 02142-0635A-000
SUB: 02142B0635AN000		 SCREW 2 Rp6.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
