FIG.187A RADIATOR HOSE (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.187A RADIATOR HOSE (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1 17670-12K11-000
SUB: 17670-12K10-000		 THERMOSTAT, WATER 1 Rp89.500
2 17661-12K02-000
SUB: 17661-12K00-000		 COVER, THERMOSTAT 1 Rp23.000
3 01547-0620B-000
SUB: 01547B0620AN000		 BOLT 2 Rp6.500
4 17851-23K00-000 HOSE, RADIATOR INLET 1 Rp46.000
5 17852-12K10-000
SUB: 17852-12K00-000		 HOSE, RADIATOR OUTLET 1 Rp15.000
6 17856-12K00-000 HOSE, WATER BYPASS 1 Rp11.500
7 09401-10417-000 CLIP 2 Rp5.000
8 DISCONTINUE
SUB: 09401-20414-000		 CLIP 2 -
9 DISCONTINUE
SUB: 09402-27002-000		 CLAMP 2 -
10 17910-23K00-000 TANK ASSY, RESERVOIR 1 Rp51.000
11 17931-31J10-000 _CAP, WATER RESERVOIR TANK 1 Rp32.000
12 17920-23K00-000 BRACKET, RESERVOIR TANK 1 Rp19.500
13 17981-23K00-000 HOSE, RESERVOIR TANK INLET 1 Rp14.500
14 09111-06063-000
SUB: 09111B06063N000		 BOLT (6X12) 2 Rp3.500
15 09352-50007-280
SUB: 09352-50001-280		 HOSE 1 Rp7.000
16 09401-08402-000
SUB: 09401B08402N000		 CLIP 2 Rp2.000
17 01547-0610A-000
SUB: 01547B0612AN000		 BOLT 2 Rp3.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
