FIG.112A CRANKCASE COVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.112A CRANKCASE COVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1 11340-12K20-000 COVER, CLUTCH 1 Rp579.000
2 11971-45010-000
SUB: 11971B45010N000		 _LENS, OIL LEVEL CHECK 1 Rp33.500
3 11482-12K00-000 GASKET, CLUTCH COVER 1 Rp23.000
4 09206-08008-000 PIN (63X8X12) 2 Rp4.000
5 01547-0630A-000 BOLT 10 Rp6.500
6 09168-06018-000
SUB: 09168B06018N000		 GASKET (62X13X12) 1 Rp8.500
7 01547-0610A-000
SUB: 01547B0612AN000		 BOLT 1 Rp3.000
8 11342-25G00-000
SUB: 11342B25G00N000		 PLUG, OIL FILLER 1 Rp19.000
9 09280-17003-000 O RING (D:31,ID:168) 1 Rp2.000
10 09168-10L02-000
SUB: 09168B10L02N000		 GASKET 1 Rp2.500
11 01500-1016A-000
SUB: 01500B1016AN000		 BOLT 1 Rp7.500
12 11351-12K20-000 COVER, MAGNETO 1 Rp269.500
13 11483-12K00-000 GASKET, MAGNETO COVER 1 Rp15.500
14 01547-0640B-000
SUB: 01547B0640AN000		 BOLT 10 Rp7.000
15 09259-36031-000 PLUG 1 Rp19.500
16 09280-33004-000 O RING (D:31,ID:327) 1 Rp12.500
17 11352-22J00-000 PLUG,TOP 1 Rp7.000
18 09280-14003-000
SUB: 09280-14003L000		 O RING (D:24,ID:138) 1 Rp3.000
19 09206-08008-000 PIN (63X8X12) 2 Rp4.000
20 11360-12K00-000 COVER, ENGINE SPROCKET 1 Rp44.000
21 01547-0630A-000 BOLT 2 Rp6.500
22 09206-08008-000 PIN (63X8X12) 2 Rp4.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
