FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.19 EMISSION CONTROL

FIG.19 EMISSION CONTROL
No No. Part Description Qty Price Per Pcs Remarks
1 DISCONTINUE
SUB: 18117-52G00-000		 VALVE ASSY, DUTY FOR PURGE 1 -
2 18417-775A0-000 BRACKET 1 -
3 18562-775A1-000
SUB: 18562B775A0N000		 HOSE, PURGE 2 Rp87.000
4 09355-35006-601
SUB: 09355-35754-601		 HOSE, VAC (RGLTR TO MANF) 1 Rp66.000 L:601->170
5-1 09401-10409-000
SUB: 09401B10409N000		 CLIP 6 Rp7.500
5-2 09401-10409-000
SUB: 09401B10409N000		 CLIP 6 Rp7.500 FROM 2007-10
6 01550-0612B-000 BOLT 1 Rp16.500
7 08316-1006A-000
SUB: 08316B1006AN000		 NUT 1 Rp2.000
8 18351-775A0-000
SUB: 18351B775A0N000		 PIPE, PURGE 1 Rp69.500
9 18560-76A31-000 CANISTER 1 Rp1.041.500
10 18561-775A0-000
SUB: 18561B775A0N000		 HOSE, PURGE 1 Rp22.500
11 18571-65H20-000
SUB: 18571B65H20N000		 CAP 1 Rp11.000
12-1 09401-10409-000
SUB: 09401B10409N000		 CLIP 2 Rp7.500
12-2 09401-10409-000
SUB: 09401B10409N000		 CLIP 2 Rp7.500 FROM 2007-10

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
