FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.11 AIR CLEANER

FIG.11 AIR CLEANER
No No. Part Description Qty Price Per Pcs Remarks
1 13700-775A0-000
SUB: 13700B775A0N000		 CLEANER ASSY, AIR 1 Rp412.000
2 13780-775A0-000
SUB: 13780B775A0N000		 .ELEMENT 1 Rp127.000
3 13877-65D00-000 .COLLAR 3 Rp45.000
4 13878-65D00-000 .CUSHION 3 Rp43.000
5 13881-775A0-000
SUB: 13881B775A0N000		 HOSE, OUTLET 1 Rp142.000
6 09116-06172-000 BOLT (6X30) 3 Rp19.500
7 09402-70503-000
SUB: 09402-69511-000		 CLAMP 2 Rp91.500
8 13870-775A0-000
SUB: 13870B775A0N000		 BOX, SUCTION 1 Rp68.000
9 13871-775A0-000 SEAL 1 Rp41.500
10 13872-775A0-000
SUB: 13872B775A0N000		 HOSE, INLET 1 Rp119.000
11 09402-70503-000
SUB: 09402-82511-000		 CLAMP 1 Rp91.500
12 01550-0612B-000 BOLT 2 Rp16.500
13 11191-775A0-000
SUB: 11191B775A0N000		 HOSE, BREATHER 1 Rp59.500
14 11199M68K00-000
SUB: 09401M18404-000		 CLIP 2 Rp11.000
15 09403-18305-000 CLAMP 1 Rp18.500
16 13650-52G00-000 SENSOR, AIR TEMP 1 Rp762.500
17 13655-77E10-000
SUB: 13655-77E00-000		 GROMMET 1 Rp30.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
