FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.3 CYLINDER BLOCK

FIG.3 CYLINDER BLOCK
No No. Part Description Qty Price Per Pcs Remarks
1 11200-58B05-000
SUB: 11200-77511L000		 BLOCK ASSY, CYLINDER 1 Rp17.486.000
2 09241M30010-000 .PLUG 4 Rp5.500
3 09246M06001-000
SUB: 09246M06002-000		 .PLUG, OIL GALLERY INNER 1 Rp19.500
4 09246M06001-000
SUB: 09246M06002-000		 .PLUG, OIL GALLERY OUTER 1 Rp19.500
5 09246-08002-000 .PLUG, OIL GALLERY 2 Rp21.500
6 11260-50G01-000 .BOLT, CRANK BEARING CAP 10 Rp41.500
7 11221-60A00-000 .PLATE, CYLINDER BLOCK 1 Rp53.500
8 11229-60A00-000
SUB: 11229-60A00L000		 .GASKET, CYLINDER BLOCK PLATE 1 Rp11.500
9 02122-0612A-000
SUB: 02122B0612AN000		 .SCREW 4 Rp3.500
10 11241-86FA0-000 STAND, OIL FILTER 1 Rp88.000
11 16510-61J00-000 FILTER ASSY, OIL 1 Rp37.000
12 DISCONTINUE
SUB: 11311-77501-000		 PLATE, CLUTCH HOUSING UPPER 1 -
13 DISCONTINUE
SUB: 11320-77500-000		 PLATE, CLUTCH HOUSING LOWER 1 -
14 02162-0610A-000 BOLT 2 Rp5.000
15 11213-72F02-000
SUB: 11213-72F01-000		 PLATE, BREATHER FRONT 1 Rp43.500
16 11214-72F01-000 PLATE, BREATHER REAR 1 Rp40.500
17 01550-0816A-000
SUB: 01550B0816AN000		 BOLT 2 Rp6.000
18 37820-820P0-000
SUB: 37820-82002-000		 SWITCH ASSY, OIL PRESSURE 1 Rp127.500
19 DISCONTINUE
SUB: 36895B77500N000		 WIRE, OIL PRESS SW 1 -
20 36995M57B30-000 BRACKET, WIRE 2 Rp5.500
21 DISCONTINUE
SUB: 09404-10417-000		 CLAMP 1 -
22 01550-1016A-000
SUB: 01550B1016AN000		 BOLT 1 Rp5.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
