FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.12 MUFFLER

FIG.12 MUFFLER
No No. Part Description Qty Price Per Pcs Remarks
1 14111-61J10-000 MANIFOLD, EXHAUST 1 Rp684.500
2 14120-76A41-000
SUB: 14120-76A40-000		 COVER, UPPER 1 Rp321.500
3 14130-76A40-000 COVER, LOWER 1 Rp450.000
4 14140-52G00-000 GASKET 1 Rp171.000
5 09103-06265-000
SUB: 09103-06168-000		 BOLT (6X10) 6 Rp21.500
6 09108-08246-000 STUD BOLT 7 Rp21.000
7 09159-06077-000 NUT 2 Rp17.500
8 01411-0612A-000 STUD BOLT 2 Rp11.500
9 01421-0835A-000 STUD BOLT 2 Rp13.500
10 08310-0008A-000
SUB: 08310M0008A-000		 NUT 9 Rp12.500
11 08322M0108A-000 WASHER 7 Rp5.500
12 11851-76A00-000
SUB: 11851B76A00N000		 HOOK, ENGINE 1 Rp12.500
13 14183-76A00-000 RING, SEAL 1 Rp126.500
14 14190-775A0-000
SUB: 14190B775A0N000		 PIPE, EXHAUST 1 Rp8.908.000
15 14281-79020-000
SUB: 14281B79020N000		 MOUNTING 1 Rp14.000
16 14492-67D00-000 SPRING 2 Rp64.000
17 09119-10073-000
SUB: 09119-10041-000		 BOLT (10X65) 2 Rp75.000
18 0918008095-000 SPACER 1 -
19 01550-0835A-000
SUB: 01550B0835AN000		 BOLT 1 Rp3.500
20 14182-60B01-000
SUB: 14182-60B00-000		 GASKET 1 Rp61.000
21 14281-79020-000
SUB: 14281B79020N000		 MOUNTING 2 Rp14.000
22 14300-775A0-000
SUB: 14300B775A0N000		 MUFFLER 1 Rp1.739.000
23 09159M10049-000 NUT 2 Rp10.500
24 0918008095-000 SPACER 3 -
25 01550-0835A-000
SUB: 01550B0835AN000		 BOLT 3 Rp3.500
26 18213-61J00-000
SUB: 18213-61J01-000		 SENSOR, OXYGEN 1 Rp713.500
27 36990-25G00-000 CLAMP 1 Rp13.000
28 09404-06429-000
SUB: 09404B06429N000		 CLAMP 1 Rp15.000
29 02162-0610A-000 SCREW 1 Rp5.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
