FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.8 TIMING BELT

FIG.8 TIMING BELT
No No. Part Description Qty Price Per Pcs Remarks
1 12741-53B01-000 PULLEY, CAM SHAFT TIMING 1 Rp578.500
2 01550-1225A-000 BOLT 1 Rp6.000
3 09206-05001-000 PIN (3.4X5X10) 1 Rp11.500
4 12761-71C20-000 BELT, TIMING 1 Rp211.000
5 12810-71C02-000 TENSIONER, BELT 1 Rp617.500
6 12821-61J00-000 SPRING 1 Rp6.000
7 12822-70C00-000 PLATE 1 Rp40.500
8 12823-82001-000 DAMPER 1 Rp40.500
9 12825-71C02-000 BOLT 1 Rp51.500
10 01550-0835A-000
SUB: 01550B0835AN000		 BOLT 1 Rp3.500
11 11360-71C00-000 COVER, INSIDE 1 Rp66.000
12 11390-61J01-000 COVER, OUTSIDE 1 Rp79.500
13 11480-71C00-000 SEAL SET, INSIDE COVER 1 Rp48.500
14 11394-70B00-000 SEAL, WATER PUMP 1 Rp26.500 L:28->18.5
15 11396-71C00-000 SEAL, OUTSIDE COVER 1 Rp45.500 L:1070->1050
16 09103-06285-000
SUB: 09103B06285N000		 BOLT (6X12) 2 Rp9.000
17 01550-06167-000 BOLT 2 Rp16.500
18 01550-06207-000
SUB: 01550B06207N000		 BOLT 5 Rp3.000
19 09159-06077-000 NUT 2 Rp17.500
20 01500-0625A-000
SUB: 01500B0625AN000		 BOLT, TENSIONER SPRING 1 Rp2.000
21 17512-76A00-000 STUD BOLT, PUMP CASE 1 Rp43.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
