FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.18 WATER HOSE

FIG.18 WATER HOSE
No No. Part Description Qty Price Per Pcs Remarks
1 17561-58B00-000 CAP, WATER THERMOSTAT 1 Rp209.000
2 17670-56B01-000 THERMOSTAT, WTR (82C) 1 Rp259.500
3 01550-0830A-000
SUB: 01550B0830AN000		 BOLT 2 Rp4.000
4 17550-77500-000 PIPE, WATER INLET 1 Rp691.000
5 17841-775A0-000
SUB: 17841B775A0N000		 HOSE, RADIATOR INLET 1 Rp71.000
6 17851-77500-000
SUB: 17851-77500L000		 HOSE, RADIATOR OUTLET 1 Rp46.500
7 17859-775A0-000
SUB: 17859B775A0N000		 HOSE, WATER BYPASS 1 Rp15.500
8 09280-28008-000
SUB: 09280B28008N000		 O-RING 1 Rp2.500
9 09401-14405-000 CLIP 2 Rp16.000
10 09401-30405-000 CLIP 2 Rp35.000
11 09400M45L01-000
SUB: 09400M45311-000		 CLIP 2 Rp32.500
12 02162-0610A-000 BOLT 1 Rp5.000
13 17858-77500-000 PROTECTOR 2 Rp52.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
