FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.17 RADIATOR

FIG.17 RADIATOR
No No. Part Description Qty Price Per Pcs Remarks
1 17700-775V0-000
SUB: 17700B775A0N000		 RADIATOR ASSY 1 Rp3.995.000
2 17920-775A0-000
SUB: 17920B775A0N000		 .CAP 1 Rp81.000
3 17751-72010-000 .PLUG 1 Rp57.500
4 17759-72010-000 .O RING 1 Rp17.000
5 17761-775A0-000
SUB: 17761B775A0N000		 SHROUD, FAN 1 Rp176.500
6 17791-775A0-000 SEAL, RDTR NO.1 1 -
7 17792-775A0-000 SEAL, RDTR NO.2 1 -
8 DISCONTINUE
SUB: 17810B775A0N000		 BRACKET, RDTR, RH 1 -
9 DISCONTINUE
SUB: 17821-77500L000		 BRACKET, RDTR, LH 1 -
10 17812-775A0-000 BRACKET, RDTR SEAL 1 -
11 17831-775A0-000
SUB: 17831B775A0N000		 COVER, UPPER 1 Rp71.000
12 17931-77500-000
SUB: 17931-77500L000		 TANK, RESERVE 1 Rp51.500
13 17932-77500-000 CAP 1 -
14 DISCONTINUE
SUB: 17933-77500L000		 RUBBER 1 -
15 DISCONTINUE
SUB: 17934-77500L000		 HOSE 1 -
16 09122-76001-000 BOLT (6X16) 6 Rp16.500
17 09352-70121-600 HOSE, RDTR TO TANK 1 Rp155.000 L:600->360
18 09401-10409-000
SUB: 09401B10409N000		 CLIP 1 Rp7.500
19 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 4 -
20 01550-0612B-000 BOLT 4 Rp16.500
21 01550-0612B-000 BOLT 4 Rp16.500
22 01550-0612B-000 BOLT 2 Rp16.500
23 DISCONTINUE
SUB: 15851-53F50-000		 PROTECTOR 1 - L:300->100

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
