FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.9 INTAKE MANIFOLD

FIG.9 INTAKE MANIFOLD
No No. Part Description Qty Price Per Pcs Remarks
1 13110-775A0-000
SUB: 13110B775A0N000		 MANIFOLD, INTAKE 1 Rp1.064.500
2 01421-0825A-000 STUD BOLT 4 Rp13.000
3 13119-57B00-000 GASKET 1 Rp124.000
4 13161-775A0-000 STIFFENER 1 -
5 01550-0825A-000
SUB: 01550B0825AN000		 BOLT 7 Rp3.500
6 01550-1025A-000
SUB: 01550B1025AN000		 BOLT 1 Rp3.500
7 08316-1008A-000
SUB: 08316B1008AN000		 NUT 4 Rp3.500
8 11851-61J00-000 HOOK, ENGINE 1 Rp39.500
9 11193-775A0-000
SUB: 11193B775A0N000		 HOSE, PCV 1 Rp31.000
10 11198M79F00-000
SUB: 11198M58B00-000		 SEAL 1 Rp16.500
11 18118-61J00-000 VALVE, PCV 1 Rp160.000
12 09401-13414-000 CLIP 1 Rp18.000
13 09401-14405-000 CLIP 1 Rp16.000
14 13650-50G10-000 SENSOR, WATER TEMP 1 Rp585.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
