FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.6 CRANKSHAFT

FIG.6 CRANKSHAFT
No No. Part Description Qty Price Per Pcs Remarks
1-2 12111-61J60-0B0
SUB: 12111-61J50-0B0		 PISTON (STD,MARK 2) 4 Rp150.000
1-3 12111-61J60-050
SUB: 12111-61J50-050		 PISTON (OS:0.5) 4 Rp150.000
1-1 12111-61J60-0A0
SUB: 12111-61J50-0A0		 PISTON (STD,MARK 1) 4 Rp150.000
2-1 12140-61J00-000 RING SET, PISTON (STD) 4 Rp98.500
2-2 12140-61J00-050 RING SET, PISTON (OS:0.5) 4 Rp98.500
3 12151-86501-000 PIN, PISTON 4 Rp58.000
4 09381-19001-000 CIRCLIP 4 Rp14.500
5 12160-75C10-000
SUB: 12160-75C00-000		 CONNROD ASSY 4 Rp963.500
6 09159M08033-000 .NUT 8 Rp14.000
7-1 12100-60822-0A0
SUB: 12100-60821-0A0		 BEARING SET, CONNROD (STD,T:1.5) 4 Rp166.000
7-2 12100-60822-025
SUB: 12100-60821-025		 BEARING SET, CONNROD (US:0.25,T:1.625) 4 Rp163.000
8 12221-75C00-000 CRANKSHAFT 1 Rp8.355.000
9-10 12300-58810-0EA BEARING SET, CRANKSHAFT (US:0.25,T:2.125,RED/BLUE) 5 Rp265.500
9-9 12300-58810-0DA BEARING SET, CRANKSHAFT (US:0.25,T:2.125,RED/YELLOW) 5 Rp256.500
9-8 12300-57820-0EA
SUB: 12300-58820-0CA		 BEARING SET, CRANKSHAFT (US:0.25,T:2.125,RED/NON) 5 Rp266.500
9-7 12300-57820-0DA
SUB: 12300-58820-0BA		 BEARING SET, CRANKSHAFT (US:0.25,T:2.125,RED/BLACK) 5 Rp297.500
9-6 12300-57820-0CA
SUB: 12300-58820-0AA		 BEARING SET, CRANKSHAFT (US:0.25,T:2.125,RED/GREEN) 5 Rp268.500
9-4 12340-58B00-0D0 BEARING SET, CRANKSHAFT (STD,T:2,YELLOW) 5 Rp176.500
9-3 12340-57K02-0E0
SUB: 12340-58BA0-0C0		 BEARING SET, CRANKSHAFT (STD,T:2,NON) 5 Rp198.500
9-2 12340-57K02-0D0
SUB: 12340-58BA0-0B0		 BEARING SET, CRANKSHAFT (STD,T:2,BLACK) 5 Rp219.000
9-1 12340-57K02-0C0
SUB: 12340-58BA0-0A0		 BEARING SET, CRANKSHAFT (STD,T:2,GREEN) 5 Rp190.500
9-5 12340-58B00-0E0 BEARING SET, CRANKSHAFT (STD,T:2,BLUE) 5 Rp192.000
10-1 12300-78890-000
SUB: 12300-60850-000		 BEARING SET, CRANK THRUST (STD,T:2.5) 1 Rp172.500
10-2 12300-78890-012
SUB: 12300-60850-012		 BEARING SET, CRANK THRUST (OS:0.125,T:2.563) 1 Rp167.500
11 12739M78L00-000
SUB: 09283M32042-000		 SEAL, FRONT OIL (32X47X6) 1 Rp35.000
12 12610-61G00-000 PULLEY, CRANKSHAFT 1 Rp4.852.000
13 08341M31059-000 KEY 1 Rp4.500
14 12619-53B01-000 BOLT 1 Rp83.000
15 09103-06185-000 BOLT (6X20) 5 Rp14.500
16 12630-52G01-000
SUB: 12630-52G00-000		 PULLEY, CRANK TIMING BELT 1 Rp295.500
17 12620-77551-000 FLYWHEEL 1 Rp923.500
18 09100-10275-000
SUB: 09103-10305-000		 BOLT (10X18.5) 6 Rp30.500
19 12623-61J00-000
SUB: 12623-71C00L000		 BEARING, INPUT SHAFT 1 Rp39.500
20 09206-06005-000
SUB: 09206B06005N000		 PIN 1 Rp14.500
21 09283-68002-000 SEAL, REAR OIL (68X86X8) 1 Rp254.500
22 11341-82001-000 HOUSING, OIL SEAL 1 Rp304.500
23 11349-60A01-000 GASKET, OIL SEAL HOUSING 1 Rp58.000
24 01550-0620B-000
SUB: 01550B0620AN000		 BOLT 3 Rp3.500
25 DISCONTINUE
SUB: 01550B0625AN000		 BOLT 2 -
26 04211M09109-000 PIN 2 Rp5.500
27 DISCONTINUE
SUB: 12651B775A0N000		 COVER, ENG SPLASH 1 -
28 09409-08333-000 CLIP 4 Rp14.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
