FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.5 ENGINE MOUNTING

FIG.5 ENGINE MOUNTING
No No. Part Description Qty Price Per Pcs Remarks
1 11610-61J10-000 MOUNTING, ENGINE FR 2 Rp384.000
2 11616-85001-000 COVER, FR MTG, LH 1 Rp22.000
3 11630-775A0-000
SUB: 11630B775A0N000		 MEMBER, ENG FR 1 Rp1.141.000
4 DISCONTINUE
SUB: 11640B775A0N000		 BRACKET, ENG FR MTG, R 1 -
5 11650-61J00-000 BRACKET, ENG FR MTG, L 1 Rp293.500
6 11684-68H00-000 CUSHION, LOWER 1 Rp43.000
7 11686-68H00-000 CUSHION, UPPER 1 Rp32.500
8 11687-67H00-000 COLLAR 4 Rp28.500
9 09116-10173-000
SUB: 09116-10132-000		 BOLT (10X72.5) 4 Rp32.000
10 01421-1025A-000 STUD BOLT 1 Rp20.000
11 01550-1025A-000
SUB: 01550B1025AN000		 BOLT 4 Rp3.500
12 01550-1025A-000
SUB: 01550B1025AN000		 BOLT 3 Rp3.500
13 08316-1010A-000
SUB: 08316B1010AN000		 NUT 4 Rp3.500
14 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
15 11710-77500-000 MOUNTING, ENG RR 1 Rp920.500
16 DISCONTINUE
SUB: 11741-775A0-000		 BRACKET, ENG REAR MTG, R 1 -
17 DISCONTINUE
SUB: 11745-775A0-000		 BRACKET, ENG REAR MTG, L 1 -
18 01550-0816A-000
SUB: 01550B0816AN000		 BOLT 4 Rp6.000
19 01550-1090A-000 BOLT 1 Rp31.000
20 01551-1025A-000 BOLT 2 Rp29.000
21 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
22 DISCONTINUE
SUB: 11851-62B00-000		 HOOK, ENG RR 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
