FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.10 THROTTLE BODY

FIG.10 THROTTLE BODY
No No. Part Description Qty Price Per Pcs Remarks
1 13400-76A31-000 BODY ASSY, THROTTLE 1 Rp12.430.000
2 13420-52G00-000 .SENSOR, THROTTLE POSITION 1 Rp2.393.500
3 02112-7412A-000 .SCREW 2 Rp14.000
4 18590-79F00-000 .SENSOR, PRESSURE 1 Rp2.263.000
5 02112-7412A-000 .SCREW 2 Rp14.000
6 18117-76A31-000 .VALVE, ISC 1 Rp2.538.000
7 14139-70G30-000
SUB: 14139M70G30-000		 .GASKET 1 Rp38.500
8 02112-3516A-000 .SCREW 4 Rp39.500
9 13421-60G00-000 GASKET 1 Rp29.500
10 01550-0850A-000 BOLT 2 Rp3.500
11 DISCONTINUE
SUB: 01421-0855A-000		 STUD BOLT 2 -
12 08316-1008A-000
SUB: 08316B1008AN000		 NUT 2 Rp3.500
13 15910-775A0-000
SUB: 15910B775A0N000		 CABLE ASSY, ACCEL 1 Rp104.000
14 DISCONTINUE
SUB: 15921-76A30-000		 BRACKET 1 -
15 DISCONTINUE
SUB: 09403-08404-000		 CLAMP 1 -
16 DISCONTINUE
SUB: 03111-0612A-000		 SCREW 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
