FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 ENGINE GASKET SETFIG.2 CYLINDER HEADFIG.3 CYLINDER BLOCKFIG.4 OIL PANFIG.5 ENGINE MOUNTINGFIG.6 CRANKSHAFTFIG.7 CAM SHAFTFIG.8 TIMING BELTFIG.9 INTAKE MANIFOLDFIG.10 THROTTLE BODYFIG.11 AIR CLEANERFIG.12 MUFFLERFIG.13 FUEL PUMPFIG.14 DELIVERY PIPEFIG.15 OIL PUMPFIG.16 WATER PUMPFIG.17 RADIATORFIG.18 WATER HOSEFIG.19 EMISSION CONTROLFIG.20 LABEL

FIG.16 WATER PUMP

FIG.16 WATER PUMP
No No. Part Description Qty Price Per Pcs Remarks
1 17400-61820-000 PUMP ASSY, WATER 1 Rp1.215.000
2 17431-60A00-001
SUB: 17431-60A00L000		 .GASKET, WATER PUMP 1 Rp22.500
3 09103-06066-000 BOLT (6X23) 3 Rp16.000
4 01421-0620A-000
SUB: 01421B0620AN000		 STUD BOLT 2 Rp3.500
5 08316-1006A-000
SUB: 08316B1006AN000		 NUT 2 Rp2.000
6 17511-775A0-000 PULLEY, WATER PUMP 1 Rp407.500
7 01580-0650A-000 BOLT 4 Rp21.000
8 17521-86550-000
SUB: 17521-86500L000		 BELT, WATER PUMP 1 Rp64.500
9 17110-77300-000 FAN, ENG COOLING 1 Rp406.500
10 17131-80000-000
SUB: 17131B80000N000		 HUB, FAN 1 Rp56.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
