Suzuki S-Presso

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FRONT SUSPENSIONFRONT DRIVE SHAFT (MT)FRONT DRIVE SHAFT (AGS)FRONT SUSPENSION FRAMEREAR SUSPENSIONROAD WHEEL/TIRESTEERING WHEELSTEERING COLUMNSTEERING UNITPEDAL/PEDAL BRACKET (5MT)PEDAL/PEDAL BRACKET (5AGS)BRAKE MASTER CYLINDERBRAKE PIPINGANTI LOCK BRAKE SYSTEMFRONT WHEEL BRAKEREAR WHEEL BRAKEPARKING BRAKE

FRONT DRIVE SHAFT (AGS)

FRONT DRIVE SHAFT (AGS)
No No. Part Description Qty Price Per Pcs Remarks
1 44101M62S10-000 SHAFT ASSY,FRONT DRIVE,RH 1 Rp3.185.500
2 44116M62S10-000 .JOINT ASSY,DIFF SIDE 1 Rp1.671.500
3 44119M62SB0-000 ..BOOT SERV KIT,TP JOINT 1 Rp365.500
4 27182M62SB0-000 ...RING SERVICE KIT 1 Rp221.500
5 44122M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
6 44121M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
7 44125M62SB0-000 .BOOT SERV KIT,C/V JOINT 1 Rp357.000
8 44123M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
9 44124M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
10 44111M65L10-000 .CIRCLIP,JOINT 1 Rp213.500
11 DISCONTINUE
SUB: 44141M62SB0-000		 .GREASE SERVICE KIT 1 -
12 DISCONTINUE
SUB: 44140M62SB0-000		 .GREASE SERVICE KIT 1 -
13 44102M62S10-000 SHAFT ASSY,FRONT DRIVE,LH 1 Rp3.185.500
14 44116M62S10-000 .JOINT ASSY,DIFF SIDE 1 Rp1.671.500
15 44119M62SB0-000 ..BOOT SERV KIT,TP JOINT 1 Rp365.500
16 27182M62SB0-000 ...RING SERVICE KIT 1 Rp221.500
17 44122M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
18 44121M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
19 44125M62SB0-000 .BOOT SERV KIT,C/V JOINT 1 Rp357.000
20 44123M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
21 44124M62SB0-000 ...CLAMP,BOOT 1 Rp171.000
22 44111M65L10-000 .CIRCLIP,JOINT 1 Rp213.500
23 DISCONTINUE
SUB: 44141M62SB0-000		 .GREASE SERVICE KIT 1 -
24 DISCONTINUE
SUB: 44140M62SB0-000		 .GREASE SERVICE KIT 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
