SHOGUN (FL125)

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.19 STARTER MOTORFIG.20 MAGNETO (FL125SDK7/SDK8/RDK8/RCDMK7/RCDMK8)FIG.20A MAGNETO (FL125RCDFK8)FIG.21 BATTERYFIG.22 ELECTRICAL (FL125SDK7/SDK8/RDK8/RCDMK/7/RCDMK8)FIG.22A ELECTRICAL (FL125RCDFK8)FIG.23 SPEEDOMETER (FL125SDK7/SDK8/RDK8/RCDMK7/RCDMK8)FIG.23A SPEEDOMETER (FL125RCDFK8)FIG.24 HEAD LAMPFIG.25 FRONT TURN SIGNAL LAMPFIG.26 REAR COMBINATION LAMPFIG.27 WIRING HARNESSFIG.27A WIRING HARNESS (FL125RCDFK8)

FIG.26 REAR COMBINATION LAMP

FIG.26 REAR COMBINATION LAMP
No No. Part Description Qty Price Per Pcs Remarks
1 DISCONTINUE
SUB: 33652B16H10N000		 CUSHION, REAR COMB 1 - 20X40X10
2 35710-16H00-000
SUB: 35710B16H00N000		 LAMP ASSY, REAR COMB 1 Rp409.000
3 35712-16H00-000
SUB: 35712B16H00N000		 •LENS 1 Rp25.500
4 35713-16H00-000
SUB: 35713B16H00N000		 •GASKET 1 Rp5.500
5 09471-12114AS01
SUB: 09471B12203N000		 •BULB (12V10W) 2 Rp14.000
6 03211-0412A-000 •SCREW 4 Rp11.500
7 DISCONTINUE
SUB: 35810B16H00N000		 •LAMP ASSY REAR COMB UNIT (LED) 1 -
8 35720-16H00-000
SUB: 35720B16H00N000		 BRACKET, REAR COMB 1 Rp10.000
9 35725-16H00-000
SUB: 35725B16H00N000		 BOLT, REAR COMB LAMP UNDER 1 Rp6.500
10 48211-09G00-000
SUB: 48211B09G00N000		 SPACER, REAR COMB 1 Rp3.000
11 DISCONTINUE
SUB: 09148-05052-000		 NUT 1 -
12 09160-05045-000
SUB: 09160B05045N000		 WASHER (5.5X18X1.0) 5 Rp4.500
13 09320-09016-000
SUB: 09320-09016L000		 CUSHION 5 Rp4.000
14 01547-0610A-000
SUB: 01547B0612BN000		 BOLT, REAR COMB BRK 2 Rp3.000
15 03541-0516A-000
SUB: 03541B0516BN000		 SCREW, REAR COMB 2 Rp3.500
16 03541-0516A-000
SUB: 03541B0516BN000		 SCREW, REAR LAMP UNDER 2 Rp3.500
17 35910-16H00-000
SUB: 35910B16H00N000		 LAMP ASSY, LICENSE 2 Rp61.000
18 09471-12081-000
SUB: 09471B12081N000		 •BULB (12V5W) 1 Rp11.000
19 09160-05501-000 WASHER (5.5X20X1.2) 2 Rp12.000
20 03541-0516A-000
SUB: 03541B0516BN000		 SCREW, LICENSE LAMP 2 Rp3.500
21 35970-16H00-000 REFLEX, REFLECTOR ASSY, REAR 1 Rp18.500
22 DISCONTINUE
SUB: 08316B1005BN000		 NUT, REAR RR 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
