  5. FIG.355A HANDLE SWITCH (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

GSXR-150

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.301A STARTING MOTORFIG.303A MAGNETOFIG.310A BATTERYFIG.312A ELECTRICAL (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.312B ELECTRICAL (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.330A SPEEDOMETERFIG.333A HEADLAMP (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.333B HEADLAMP (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.334A TURNSIGNAL LAMPFIG.339A REAR COMBINATION LAMPFIG.350A WIRING HARNESS (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.350B WIRING HARNESS (GSX-R150RFL7 P12/GSX-S150MFXL7 P12)FIG.352A LOCK SET (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.352B LOCK SET (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.355A HANDLE SWITCH (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.355A HANDLE SWITCH (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.355A HANDLE SWITCH (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1 37200-23K03-000
SUB: 37200-23K00-000		 SWITCH ASSY, HANDLE RH 1 Rp215.000
2 02112-0530B-000
SUB: 02112B0530BN000		 _SCREW 1 Rp5.500
3 02112-0545B-000 _SCREW 1 Rp21.500
4 09407-14407-000 CLAMP (L:145) 1 Rp18.500
5 37400-23K00-000 SWITCH ASSY, HANDLE LH 1 Rp226.000
6 DISCONTINUE
SUB: 02112-0520B-000		 _SCREW 1 -
7 02112-0540B-000 _SCREW 1 Rp22.500
8 09407-14407-000 CLAMP (L:145) 1 Rp18.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
