STEERING COLUMN (5MT:GX)

STEERING COLUMN (5MT:GX)
No No. Part Description Qty Price Per Pcs Remarks
1 48200M66R41-000 COLUMN ASSY, COLPS STRG 1 Rp10.824.000
2 48215-74P00-000 BOLT 1 Rp36.500
3 09117M08111-000 BOLT 1 Rp8.500
4 09159-08127-000
SUB: 09159M08153-000		 NUT 1 Rp11.000
5 09159-12001-000 NUT 1 Rp90.500
6 48400M66R10-5PK COVER ASSY, STEERING COLUMN (BLACK) 1 Rp128.000
7 48481M66R00-000 COVER, STRG JOINT 1 Rp18.000
8 09136M05030-000 SCREW (5X12) 1 Rp4.500
9 03211M0512A-000 SCREW 2 Rp4.500
10 DISCONTINUE
SUB: 79172-80G02-000		 LABEL, STRG JOINT 1 -
11 48431-62R00-000 PLATE,KNEE PROTECTOR 1 Rp142.500
12 48435-62R00-000 PAD,STRG COLUMN COVER 1 Rp186.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
