| 1 |
12111M83P00-000 |
PISTON |
4 |
Rp159.500 |
| |
| 2 |
09381-18002-000
SUB: 09381B18002N000 |
CIRCLIP |
8 |
Rp2.500 |
| |
| 3 |
12140M68P00-000 |
RING SET, PISTON |
4 |
Rp128.500 |
| |
| 4 |
12151M68K60-000 |
PIN, PISTON |
4 |
Rp34.500 |
| |
| 5 |
12160M83K00-000 |
CONNROD ASSY |
4 |
Rp392.500 |
| |
| 6 |
12163-69J00-000 |
•BOLT, CONNROD |
8 |
Rp25.500 |
| |
| 7-4 |
12181M68K00-0D0 |
BEARING, CONNROD YELLOW (STD,T:1.5) |
8 |
Rp20.500 |
| |
| 7-6 |
12181M68K00-025 |
BEARING, CONNROD RED (US:0.25,T:1.625) |
8 |
Rp95.500 |
| |
| 7-5 |
12181M68K00-0E0 |
BEARING, CONNROD BLUE (STD,T:1.5) |
8 |
Rp22.000 |
| |
| 7-3 |
12181M68K00-0C0 |
BEARING, CONNROD NON (STD,T:1.5) |
8 |
Rp20.500 |
| |
| 7-2 |
12181M68K00-0B0 |
BEARING, CONNROD BLACK (STD,T:1.5) |
8 |
Rp20.500 |
| |
| 7-1 |
12181M68K00-0A0 |
BEARING, CONNROD GREEN (STD,T:1.5) |
8 |
Rp20.500 |
| |
| 8 |
12221M83K20-000 |
CRANKSHAFT |
1 |
Rp3.601.000 |
| |
| 9-2 |
12341M74L00-0B0 |
BEARING, CRANK UPR PURPLE (STD,T:2) |
5 |
Rp30.500 |
| |
| 9-10 |
12341-74L00-0EA
SUB: 12341M74L00-0EA |
BEARING, CRANK UPR RED/BLACK |
5 |
Rp61.500 |
| |
| 9-9 |
12341-74L00-0DA
SUB: 12341M74L00-0DA |
BEARING, CRANK UPR RED/GREEN |
5 |
Rp61.500 |
| |
| 9-8 |
12341-74L00-0CA
SUB: 12341M74L00-0CA |
BEARING, CRANK UPR RED/BROWN |
5 |
Rp61.500 |
| |
| 9-7 |
12341-74L00-0BA
SUB: 12341M74L00-0BA |
BEARING, CRANK UPR RED/PURPLE |
5 |
Rp61.500 |
| |
| 9-6 |
12341-74L00-0AA
SUB: 12341M74L00-0AA |
BEARING, CRANK UPR RED/PINK |
5 |
Rp59.500 |
| |
| 9-5 |
12341M74L00-0E0 |
BEARING, CRANK UPR BLACK (STD,T:2) |
5 |
Rp30.500 |
| |
| 9-4 |
12341M74L00-0D0 |
BEARING, CRANK UPR GREEN (STD,T:2) |
5 |
Rp30.500 |
| |
| 9-3 |
12341M74L00-0C0 |
BEARING, CRANK UPR BROWN (STD,T:2) |
5 |
Rp30.500 |
| |
| 9-1 |
12341M74L00-0A0 |
BEARING, CRANK UPR PINK (STD,T:2) |
5 |
Rp30.500 |
| |
| 10-4 |
12345M74L00-0D0 |
BEARING, CRANK LWR GREEN (STD,T:2) |
5 |
Rp29.000 |
| |
| 10-10 |
12345-74L00-0EA
SUB: 12345M74L00-0EA |
BEARING, CRANK LWR RED/BLACK |
5 |
Rp61.000 |
| |
| 10-9 |
12345-74L00-0DA
SUB: 12345M74L00-0DA |
BEARING, CRANK LWR RED/GREEN |
5 |
Rp61.000 |
| |
| 10-8 |
12345-74L00-0CA
SUB: 12345M74L00-0CA |
BEARING, CRANK LWR RED/BROWN |
5 |
Rp61.000 |
| |
| 10-7 |
12345-74L00-0BA
SUB: 12345M74L00-0BA |
BEARING, CRANK LWR RED/PURPLE |
5 |
Rp61.000 |
| |
| 10-5 |
12345M74L00-0E0 |
BEARING, CRANK LWR BLACK (STD,T:2) |
5 |
Rp30.000 |
| |
| 10-3 |
12345M74L00-0C0 |
BEARING, CRANK LWR BROWN (STD,T:2) |
5 |
Rp29.000 |
| |
| 10-2 |
12345M74L00-0B0 |
BEARING, CRANK LWR PURPLE (STD,T:2) |
5 |
Rp29.000 |
| |
| 10-1 |
12345M74L00-0A0 |
BEARING, CRANK LWR PINK (STD,T:2) |
5 |
Rp29.000 |
| |
| 10-6 |
12345-74L00-0AA
SUB: 12345M74L00-0AA |
BEARING, CRANK LWR RED/PINK |
5 |
Rp59.000 |
| |
| 11-1 |
12351-58M00-000 |
BEARING, CRANK THRUST (STD,T:2.5) |
2 |
Rp41.000 |
| |
| 11-2 |
12351-58M00-012 |
BEARING, CRANK THRUST |
2 |
Rp62.000 |
| |
| 12 |
16141M68K00-000 |
OIL SEAL, CRANKSHAFT FRONT (41X53X6) |
1 |
Rp53.500 |
| |
| 13 |
12222M68P00-000 |
PLATE, SENSOR |
1 |
Rp50.500 |
| |
| 14 |
12223-69G00-000 |
SCREW, SENSOR PLATE |
2 |
Rp13.500 |
| |
| 15 |
09205-05006-000 |
SPRING PIN (5X12) |
1 |
Rp11.500 |
| |
| 16 |
12610-81P00-000 |
PULLEY, CRANKSHAFT |
1 |
Rp1.230.500 |
| |
| 17 |
12619M84MA0-000 |
BOLT, CRANK PULLEY |
1 |
Rp95.000 |
| |
| 18 |
12631M83K11-000 |
SPROCKET, CRANKSHAFT TIMING |
1 |
Rp228.500 |
| |
| 19 |
08341M31059-000 |
KEY |
1 |
Rp4.500 |
| |
| 20 |
11341M51K00-000 |
HOUSING, OIL SEAL |
1 |
Rp73.000 |
| |
| 21 |
11342M68K10-000 |
OIL SEAL, CRANKSHAFT REAR |
1 |
Rp143.000 |
| |
| 22 |
09103M06315-000 |
BOLT (6X25) |
6 |
Rp6.000 |
| |
| 23 |
04221-06129-000 |
PIN (4X6X11) |
2 |
Rp12.500 |
| |
| 24 |
17521M68PA0-000 |
BELT, WATER PUMP |
1 |
Rp105.000 |
| |
| 25 |
12620-77M01-000
SUB: 12620M68K00-000 |
FLYWHEEL |
1 |
Rp766.000 |
| |
| 26 |
12623M68K00-000 |
BEARING, INPUT SHAFT |
1 |
Rp88.000 |
| |
| 27 |
09103-10440-000 |
BOLT (10X18.5) |
6 |
Rp33.000 |
| |
| 28 |
11345M68K00-000 |
PIN,OIL SEAL HOUSING DOWE |
2 |
Rp5.500 |
| |
