NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.300A ENGINE ELECTRICALFIG.302A STARTING MOTORFIG.304A GENERATORFIG.320A BATTERY (5MT:SEE NOTE)FIG.320B BATTERY (4AT:SEE NOTE)FIG.324A SPEEDOMETERFIG.330A HEADLAMPFIG.332A FRONT FOG LAMPFIG.336A REAR LAMPFIG.338A ROOM LAMPFIG.348A ENGINE HARNESS BRACKET (5MT)FIG.348B ENGINE HARNESS BRACKET (4AT)FIG.34NA WIRING HARNESS FRONT SIDEFIG.34PA WIRING HARNESS REAR SIDEFIG.350A ELECTRICAL CONTROL BODYFIG.351A ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360A LOCK SETFIG.370A FRONT WINDOW WIPERFIG.374A WINDOW WASHERFIG.376A REAR WINDOW WIPERFIG.392A AUDIO

FIG.392A AUDIO

FIG.392A AUDIO
No No. Part Description Qty Price Per Pcs Remarks
1 990H0-990AE-037
SUB: 990H0-990AE-029		 HEAD UNIT TOUCH SCREEN 6.8 SET 1 Rp3.957.500
2 03541-0410A-000 SCREW 2 Rp11.000
3 39105M56R00-5PK SOCKET, USB & AUX (BLACK) 1 Rp133.000
4 39106M68P10-000 CABLE, USB & AUX 1 Rp409.500
5 39321M68P00-000 BRACKET, TUNER RH 1 Rp35.000
6 39322M68P00-000 BRACKET, TUNER LH 1 Rp35.000
7 34955M79M00-000 BUSH, RADIO BRKT 2 Rp18.500
8 09132-05049-000 SCREW (5X12) 2 Rp21.000
9 02142-0508A-000
SUB: 02142B0508AN000		 SCREW 6 Rp3.500
10 39251M74LA0-000
SUB: 39251M74L00-000		 ROD, ANTENNA 1 Rp97.500
11 39253M74LA0-000
SUB: 39253M74L11-000		 BASE, ANTENNA 1 Rp818.500
12 39270M68P00-000 FEEDER, I/P 1 Rp245.000
13 39271M68P10-000 FEEDER, ROOF 1 Rp345.000
14 39102M69P00-000 SPEAKER ASSY 4 Rp198.000
15 39102M65M00-000 SPEAKER ASSY, TWEETER 2 Rp227.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
