NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.300A ENGINE ELECTRICALFIG.302A STARTING MOTORFIG.304A GENERATORFIG.320A BATTERY (5MT:SEE NOTE)FIG.320B BATTERY (4AT:SEE NOTE)FIG.324A SPEEDOMETERFIG.330A HEADLAMPFIG.332A FRONT FOG LAMPFIG.336A REAR LAMPFIG.338A ROOM LAMPFIG.348A ENGINE HARNESS BRACKET (5MT)FIG.348B ENGINE HARNESS BRACKET (4AT)FIG.34NA WIRING HARNESS FRONT SIDEFIG.34PA WIRING HARNESS REAR SIDEFIG.350A ELECTRICAL CONTROL BODYFIG.351A ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360A LOCK SETFIG.370A FRONT WINDOW WIPERFIG.374A WINDOW WASHERFIG.376A REAR WINDOW WIPERFIG.392A AUDIO

FIG.300A ENGINE ELECTRICAL

FIG.300A ENGINE ELECTRICAL
No No. Part Description Qty Price Per Pcs Remarks
1 31100M71P01-000
SUB: 31100M71P00-000		 MOTOR ASSY, STARTING 1 Rp3.788.000
2 01550-1060A-000 BOLT 2 Rp5.500
3 08316-1008A-000 NUT 1 Rp3.500
4 31400M68P01-000
SUB: 31400M68P00-000		 GENERATOR ASSY 1 Rp4.703.000
5 01550-1085A-000 BOLT 1 Rp7.000
6 08316-1006A-000 NUT 1 Rp2.000
7 11551M68P00-000 BRACKET, GENERATOR 1 Rp222.500
8 11561M68P00-000 ARM, GEN BELT ADJ 1 Rp46.000
9 11562M68M00-000 ADJUSTER, GEN BELT 1 Rp10.500
10 11563-68P00-000 BOLT, GENERATOR ADJUSTING 1 Rp29.000
11 01550-0825A-000 BOLT 5 Rp3.500
12 33220M68P00-000 SENSOR ASSY, POSN 1 Rp505.500 CAM
13 33220M53M00-000 SENSOR ASSY, POSN 1 Rp883.500 CRANK
14 09103M06317-000 BOLT (6X16) 1 Rp6.500
15 01550-0616A-000 BOLT 1 Rp3.500
16-1 33400M68P00-000 COIL ASSY, IGNITION 4 Rp597.500 ID NO:NL3
16-2 33400M68P00-000 COIL ASSY, IGNITION 4 Rp597.500 ID NO:DL4
17 09135M06032-000 BOLT (6X23) 4 Rp9.000
18 33924M68P00-000 BRACKET, EPI CONT 1 Rp47.500
19 09159M06112-000 NUT 3 Rp6.500
20-1 33921M68PE1-000
SUB: 33921M68PE0-000		 CONTROLLER ASSY, EPI 1 Rp3.156.500 5MT
20-2 33921M68PF1-000
SUB: 33921M68PF0-000		 CONTROLLER ASSY, EPI 1 Rp3.012.500 4AT
21 02162-0612A-000 SCREW 2 Rp11.000
22 37820M68K00-000 SWITCH ASSY, OIL PRESSURE 1 Rp199.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
