  5. FIG.370A FRONT WINDOW WIPER

NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.300A ENGINE ELECTRICALFIG.302A STARTING MOTORFIG.304A GENERATORFIG.320A BATTERY (5MT:SEE NOTE)FIG.320B BATTERY (4AT:SEE NOTE)FIG.324A SPEEDOMETERFIG.330A HEADLAMPFIG.332A FRONT FOG LAMPFIG.336A REAR LAMPFIG.338A ROOM LAMPFIG.348A ENGINE HARNESS BRACKET (5MT)FIG.348B ENGINE HARNESS BRACKET (4AT)FIG.34NA WIRING HARNESS FRONT SIDEFIG.34PA WIRING HARNESS REAR SIDEFIG.350A ELECTRICAL CONTROL BODYFIG.351A ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360A LOCK SETFIG.370A FRONT WINDOW WIPERFIG.374A WINDOW WASHERFIG.376A REAR WINDOW WIPERFIG.392A AUDIO

FIG.370A FRONT WINDOW WIPER

FIG.370A FRONT WINDOW WIPER
No No. Part Description Qty Price Per Pcs Remarks
1 38100M68P11-000 WIPER ASSY, WINDSHIELD 1 Rp1.668.500
2 38116M72J00-000 .BOLT, WIPER DRIVER 1 Rp48.000
3 38116-82K00-000 .BOLT, WIPER ASST 1 Rp53.000
4 38310M68P10-000 ARM ASSY, WIPER DRIVER 1 Rp319.500
5 38340M68P11-000 BLADE ASSY, WIPER DRIVER 1 Rp168.500
6 38346M76M00-000 .RUBBER, BLADE 1 Rp132.000
7 38330M68P10-000 ARM ASSY, WIPER ASSISTANT 1 Rp388.000
8 38340M68P30-000 BLADE ASSY, WIPER ASSISTANT 1 Rp235.000
9 38346M68P00-000 .RUBBER 1 Rp71.000
10 38315M74L00-000 CAP, WIPER PIVOT 2 Rp5.000
11 08310-0008A-000 NUT 2 Rp12.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
