FIG.34PA WIRING HARNESS REAR SIDE

FIG.34PA WIRING HARNESS REAR SIDE
No No. Part Description Qty Price Per Pcs Remarks
1 36620M50SF0-000 HARNESS ASSY, I/P 1 Rp2.339.000
2-1 38860M76M00-000 .RELAY ASSY (DENSO) 1 Rp58.500 RR DEF
2-2 38860M76M00-000 .RELAY ASSY (INTERFACE MICROSYSTEMS) 1 Rp58.500 RR DEF
3 09115-06005-000 BOLT (6X16) 2 Rp14.000
4 02162-0612A-000 SCREW 1 Rp11.000
5 36630M50SH0-000 HARNESS ASSY, FLOOR 1 Rp1.435.500
6 09115-06005-000 BOLT (6X16) 2 Rp14.000
7 09159-08127-000 NUT 2 Rp11.000
8 36680M68P20-000 HARNESS ASSY, BACK DOOR 1 Rp231.000
9 09115-06005-000 BOLT (6X16) 1 Rp14.000
10 36710M68PA2-000 BOX ASSY, 6CTION 1 Rp1.566.500
11 36699M68PA2-000 .COVER, FUSE 1 Rp20.500
12 09481-05501-000 .FUSE (5A) 12 Rp17.000
13 09481-10504-000 .FUSE (10A) 11 Rp12.500
14 09481-15504-000 .FUSE (15A) 7 Rp13.000
15 09481-20504-000 .FUSE (20A) 5 Rp14.500
16 09481-25504-000 .FUSE (25A) 1 Rp17.500
17 09481-30403-000 .FUSE (30A) 1 Rp41.000
18 38860M76M00-000 RELAY ASSY 1 Rp58.500
19 36813M68P00-000 WIRE, RR PARK SNSR 1 Rp783.000
20 36930M70F10-000 COVER 4 Rp4.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
