NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.300A ENGINE ELECTRICALFIG.302A STARTING MOTORFIG.304A GENERATORFIG.320A BATTERY (5MT:SEE NOTE)FIG.320B BATTERY (4AT:SEE NOTE)FIG.324A SPEEDOMETERFIG.330A HEADLAMPFIG.332A FRONT FOG LAMPFIG.336A REAR LAMPFIG.338A ROOM LAMPFIG.348A ENGINE HARNESS BRACKET (5MT)FIG.348B ENGINE HARNESS BRACKET (4AT)FIG.34NA WIRING HARNESS FRONT SIDEFIG.34PA WIRING HARNESS REAR SIDEFIG.350A ELECTRICAL CONTROL BODYFIG.351A ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360A LOCK SETFIG.370A FRONT WINDOW WIPERFIG.374A WINDOW WASHERFIG.376A REAR WINDOW WIPERFIG.392A AUDIO

FIG.336A REAR LAMP

FIG.336A REAR LAMP
No No. Part Description Qty Price Per Pcs Remarks
1 35650M68P01-000 LAMP UNIT, RR COMB RH 1 Rp1.017.500
2 09471-12146-000
SUB: 09471B12146N000		 BULB (12V16W) 1 Rp39.500
3 09471-12186-000
SUB: 09471B12186N000		 BULB (12V21W) 1 Rp22.000
4 35750M68P01-000 LAMP UNIT, RR COMB LH 1 Rp1.017.500
5 09471-12146-000
SUB: 09471B12146N000		 BULB (12V16W) 1 Rp39.500
6 09471-12186-000
SUB: 09471B12186N000		 BULB (12V21W) 1 Rp22.000
7 01551-0616C-000 BOLT 4 Rp14.500
8 35153M59K10-000 GROMMET, RR COMB LAMP LWR 2 Rp8.000
9 35153M59K20-000 GROMMET, RR COMB LAMP UPR 2 Rp8.000
10 35810M68P11-000
SUB: 35810M68P10-000		 LAMP ASSY, HIGH MOUNT STOP 1 Rp608.000
11 02112-1410D-000 SCREW 2 Rp19.000
12 35910M75J11-000 LAMP ASSY, LICENSE 2 Rp51.000
13 09471-12216-000 .BULB (12V5W) 2 Rp15.000
14 35950M55K01-000 REFLECTOR ASSY, REAR RH 1 Rp54.000
15 35970M55K01-000 REFLECTOR ASSY, REAR LH 1 Rp54.000
16 03541-0516A-000 SCREW 2 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
