NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.300A ENGINE ELECTRICALFIG.302A STARTING MOTORFIG.304A GENERATORFIG.320A BATTERY (5MT:SEE NOTE)FIG.320B BATTERY (4AT:SEE NOTE)FIG.324A SPEEDOMETERFIG.330A HEADLAMPFIG.332A FRONT FOG LAMPFIG.336A REAR LAMPFIG.338A ROOM LAMPFIG.348A ENGINE HARNESS BRACKET (5MT)FIG.348B ENGINE HARNESS BRACKET (4AT)FIG.34NA WIRING HARNESS FRONT SIDEFIG.34PA WIRING HARNESS REAR SIDEFIG.350A ELECTRICAL CONTROL BODYFIG.351A ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360A LOCK SETFIG.370A FRONT WINDOW WIPERFIG.374A WINDOW WASHERFIG.376A REAR WINDOW WIPERFIG.392A AUDIO

FIG.374A WINDOW WASHER

FIG.374A WINDOW WASHER
No No. Part Description Qty Price Per Pcs Remarks
1 38410M68P00-000 PUMP ASSY, FR 1 Rp151.500
2 38410M68P10-000 PUMP ASSY, RR 1 Rp150.000
3 38450M68P10-000 TANK 1 Rp134.500
4 38452M65L00-000 CAP 1 Rp10.000
5 38453M75000-000 GROMMET 2 Rp4.500
6 38459M68P00-000 HOSE 1 Rp23.000
7 38833M67500-000 •JOINT 1 Rp6.500
8 38459M68P10-000 HOSE 1 Rp23.000
9 38480M68P01-000 NOZZLE, WASHER 1 Rp29.000
10 38480M68P10-000
SUB: 38480M68P11-000		 NOZZLE, WASHER 1 Rp27.500
11 38832M68P00-000 HOSE ASSY, WASHER 1 Rp62.500
12 02162-0612A-000 SCREW 3 Rp11.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
