FIG.330A HEADLAMP

FIG.330A HEADLAMP
No No. Part Description Qty Price Per Pcs Remarks
1 35121M50SA0-000 UNIT, HEADLAMP RH 1 Rp7.030.000
2 36118-77A00-000 SOCKET, TURN LAMP 1 Rp73.500
3 09471-12245-000
SUB: 09471B12245N000		 BULB (12V21W,PY21W) 1 Rp30.500
4 35321M50SA0-000 UNIT, HEADLAMP LH 1 Rp7.030.000
5 36118-77A00-000 SOCKET, TURN LAMP 1 Rp73.500
6 09471-12245-000
SUB: 09471B12245N000		 BULB (12V21W,PY21W) 1 Rp30.500
7 35181-71L00-000 SCREW 8 Rp22.500
8 09409M08006-000 CLIP 2 Rp5.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
