  5. FIG.350A ELECTRICAL CONTROL BODY

NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.300A ENGINE ELECTRICALFIG.302A STARTING MOTORFIG.304A GENERATORFIG.320A BATTERY (5MT:SEE NOTE)FIG.320B BATTERY (4AT:SEE NOTE)FIG.324A SPEEDOMETERFIG.330A HEADLAMPFIG.332A FRONT FOG LAMPFIG.336A REAR LAMPFIG.338A ROOM LAMPFIG.348A ENGINE HARNESS BRACKET (5MT)FIG.348B ENGINE HARNESS BRACKET (4AT)FIG.34NA WIRING HARNESS FRONT SIDEFIG.34PA WIRING HARNESS REAR SIDEFIG.350A ELECTRICAL CONTROL BODYFIG.351A ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360A LOCK SETFIG.370A FRONT WINDOW WIPERFIG.374A WINDOW WASHERFIG.376A REAR WINDOW WIPERFIG.392A AUDIO

FIG.350A ELECTRICAL CONTROL BODY

FIG.350A ELECTRICAL CONTROL BODY
No No. Part Description Qty Price Per Pcs Remarks
1 95643M67P00-000 SENSOR, OUTSIDE AIR TEMP 1 Rp189.000
2 37670M60M10-000 SWITCH ASSY, DOOR 4 Rp35.000
3 37179M68P01-000 SWITCH ASSY, BACK DOOR & KLS 1 Rp332.500
4 03541-0416A-000 SCREW 2 Rp3.500
5 37990M68P51-000 SWITCH ASSY, POWER WINDOW MA 1 Rp677.500
6 03541-0410A-000 SCREW 3 Rp11.000
7 37995M79M02-000
SUB: 37995M79M00-000		 SWITCH ASSY, POWER WINDOW SUB 3 Rp109.500
8 03541-0410A-000 SCREW 3 Rp11.000
9 37950M56R00-000 SWITCH ASSY, MIRROR 1 Rp113.500
10-1 38500M50S00-000 HORN ASSY, LOW PITCHED 1 Rp141.000
10-2 38500M68P01-000
SUB: 38500M68P00-000		 HORN ASSY, LOW PITCHED 1 Rp171.000
11 09115-08001-000 BOLT (8X18) 1 Rp21.500
12 37175M68P10-000 ANTENNA ASSY, KLS 1 Rp260.000
13 37175M68P20-000 ANTENNA ASSY, KLS LUGGAGE 1 Rp278.500
14 38590-72M00-000 BUZZER ASSY, KLS 1 Rp441.500
15 38930M68P00-000 SENSOR ASSY, FORWARD 1 Rp416.500
16 02162-0620A-000 SCREW 1 Rp5.500
17 36771-79M01-000 LABEL, SECURITY ALARM 1 Rp5.000
18 37730M68P00-000 CONTROLLER ASSY, PARK SNSR 1 Rp862.000
19 37734M79M00-000 BUZZER, PARK SNSR 1 Rp241.500
20-1 37735M68P01-ZAM SENSOR ASSY, PARK (BLACK) 4 Rp468.000
20-2 37735M68P01-ZHJ SENSOR ASSY, PARK (WHITE) 4 Rp451.500
20-3 37735M68P01-ZYR SENSOR ASSY, PARK (BLUE) 4 Rp455.500
20-4 37735M68P01-ZZP SENSOR ASSY, PARK (SILVER) 4 Rp462.000
20-5 37735M68P01-Z4Q SENSOR ASSY, PARK (RED) 4 Rp451.500
20-6 37735M68P01-Z7Q SENSOR ASSY, PARK (GRAY) 4 Rp437.000
20-7 37735M68P01-Z7Q SENSOR ASSY, PARK (ORANGE) 4 Rp437.000
21 37736M58R00-000 BRACKET, PARK SNSR HARNESS 2 Rp16.500
22 71851M70F00-000 NUT 2 Rp4.000
23 03141M0612A-000 SCREW 2 Rp4.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
