| 1 |
DISCONTINUE
SUB: 25231M75J00-000 |
FORK, 5TH GEAR SHIFT |
1 |
- |
| |
| 2 |
25401M68K00-000 |
SHAFT, LOW SPEED GEAR SHIFT |
1 |
Rp320.500 |
| |
| 3 |
25402M68K00-000
SUB: 25402M68K02-000 |
SHAFT, HIGH SPEED GEAR SHIFT |
1 |
Rp353.000 |
| |
| 4 |
DISCONTINUE
SUB: 25251M75J00-000 |
ARM, REVERSE GEAR SHIFT |
1 |
- |
| |
| 5 |
25255M60B11-000
SUB: 25255M60B01-000 |
SPRING, REV GEAR SHIFT ARM |
1 |
Rp6.500 |
| |
| 6 |
DISCONTINUE
SUB: 25261M68K00-000 |
YOKE, 5TH & REV GEAR SHIFT |
1 |
- |
| |
| 7 |
DISCONTINUE
SUB: 25431M75J00-000 |
SHAFT, 5TH & REV GR SHF GUIDE |
1 |
- |
| |
| 8 |
DISCONTINUE
SUB: 25451M68K00-000 |
SHAFT, 5TH & REV GEAR SHIFT |
1 |
- |
| |
| 9 |
09205M04009-000 |
PIN (4.5X20) |
2 |
Rp5.500 |
| |
| 10 |
06111M10004-000 |
BALL |
2 |
Rp5.500 |
| |
| 11 |
DISCONTINUE
SUB: 25460M75J00-000 |
LEVER, REVERSE GEAR SHIFT |
1 |
- |
| |
| 12 |
09128M10001-000
SUB: 09128-10002-000 |
BOLT (10X9) |
3 |
Rp5.500 |
| |
| 13 |
09205M04009-000 |
PIN (4.5X20) |
1 |
Rp5.500 |
| |
| 14 |
01570-0820B-000
SUB: 01570-0820A-000 |
BOLT |
2 |
Rp31.000 |
| |
| 15 |
08322M0110A-000 |
WASHER |
3 |
Rp4.500 |
| |
| 16 |
DISCONTINUE
SUB: 24726M67KC0-000 |
BRACKET, BREATHER HOSE |
1 |
- |
| |
| 17 |
25010M67KC2-000
SUB: 25010M67KC0-000 |
SHAFT ASSY, GEAR SHIFT/SELECT |
1 |
Rp4.637.500 |
| |
| 18 |
DISCONTINUE
SUB: 25321-86G00-000 |
BOLT, GEAR SHIFT INTERLOCK |
1 |
- |
| |
| 19 |
25584-51K00-000
SUB: 25584B51K00N000 |
BOLT, 5TH TO REV INTLK GUIDE |
1 |
Rp13.500 |
| |
| 20 |
25630M67KC1-000 |
BRACKET, CLUTCH CABLE CLAMP |
1 |
- |
| |
| 21 |
09103-08419-000 |
BOLT (8X25) |
2 |
Rp14.000 |
| |
| 22 |
09403-11314-000 |
CLAMP |
1 |
Rp24.500 |
| |
| 23 |
01550-0820A-000
SUB: 01550B0820AN000 |
BOLT |
2 |
Rp5.500 |
| |
| 24 |
01550-0825A-000
SUB: 01550B0825AN000 |
BOLT |
2 |
Rp3.500 |
| |
| 25 |
08322M0108A-000 |
WASHER |
1 |
Rp5.500 |
| |
| 26 |
08322M0110A-000 |
WASHER |
1 |
Rp4.500 |
| |
