ERTIGA TYPE 1, 2, 3

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG.95 FRONT HOOD PANEL FIG.96 FRONT FENDER (TYPE 1, TYPE 2:GA ; TYPE 3:GA,GL)FIG.97 FRONT FENDER (TYPE 1, TYPE 2:GL,GX ; TYPE 3:GX)FIG.98 FRONT BODY PANEL FIG.99 FLOOR PANEL FIG.100 SIDE BODY PANEL FIG.101 ROOF PANEL FIG.102 TIRE CARRIER FIG.103 FRONT BUMPER (TYPE 1, TYPE 2)FIG.103A FRONT BUMPER (TYPE 3)FIG.104 REAR BUMPER (TYPE 1,TYPE 2)FIG.104A REAR BUMPER (TYPE 3)FIG.105 INSTRUMENT PANEL FIG.106 VENTILATOR FIG.107 HEATER UNIT (N/REAR AIR CONDITIONER)FIG.108 HEATER UNIT (W/REAR AIR CONDITIONER)FIG.109 HEATER CONTROL FIG.110 CONSOLE BOX FIG.111 FLOOR CARPET (TYPE 1,TYPE 2)FIG.111A FLOOR CARPET (TYPE 3)FIG.112 INTERIOR TRIM FIG.113 COVER/CAP FIG.114 FUEL LID OPENER FIG.115 ROOF LINING FIG.116 ROOF MOLDING FIG.117 EMBLEM FIG.118 WINDSHIELD FIG.119 FRONT DOOR PANEL (STD,GA)FIG.120 FRONT DOOR PANEL (GL, GX)FIG.121 FRONT DOOR REGULATOR (W/MANUAL WINDOW)FIG.122 FRONT DOOR REGULATOR (W/POWER WINDOW)FIG.123 FRONT DOOR LOCK (GA)FIG.124 FRONT DOOR LOCK (DLX,SDX,GL,GX)FIG.125 REAR DOOR PANEL (GA)FIG.126 REAR DOOR PANEL (GL, GX)FIG.127 REAR DOOR REGULATOR (W/MANUAL WINDOW)FIG.128 REAR DOOR REGULATOR (W/POWER WINDOW)FIG.129 REAR DOOR LOCK (GA)FIG.130 REAR DOOR LOCK (DLX,SDX,GL,GX)FIG.131 BACK DOOR PANEL (GA)FIG.132 BACK DOOR PANEL (TYPE 1, TYPE 2 : GL,GX ; TYPE 3 : GA,GL,GX FIG.133 BACK DOOR LOCK (GA)FIG.134 BACK DOOR LOCK (GL,GX)FIG.135 MIRROR/SUNVISOR (GA)FIG.136 MIRROR/SUNVISOR (TYPE 1, TYPE 2 : GL,GX FIG.136A MIRROR/SUNVISOR (TYPE 3 : GL)FIG.136B MIRROR/SUNVISOR (TYPE 3 : GX)FIG.137 SEAT BELT (TYPE 1,TYPE 2)FIG.137A SEAT BELT (TYPE 3)FIG.138 FRONT RH SEAT (TYPE 1,TYPE 2,TYPE 3 : GA,GL)FIG.139 FRONT RH SEAT (TYPE 1, TYPE 2, TYPE 3 : GX)FIG.140 FRONT LH SEAT FIG.141 2ND RH SEAT (TYPE 1, TYPE 2 : GA)FIG.141A 2ND RH SEAT (TYPE 3 : GA)FIG.142 2ND RH SEAT ((TYPE 1, TYPE 2, TYPE 3 : GL, GX)FIG.143 2ND LH SEAT FIG.144 3RD SEAT (GA)FIG.145 3RD SEAT (TYPE 1, TYPE 2 : GL, GX)FIG.146 3RD RH SEAT (TYPE 3 : GL,GX)FIG.147 3RD LH SEAT (TYPE 3 : GL,GX)FIG.148 FUEL TANK FIG.149 TOOL FIG.150 AIR CONDITIONER (TYPE 1:N/REAR AIR CONDITIONER TO MHYKZE81SDJ121496)FIG.151 AIR CONDITIONER (TYPE 1:N/REAR AIR CONDITIONER FROM MHYKZE81SDJ121497)FIG.152 AIR CONDITIONER (TYPE 2,TYPE 3:N/REAR AIR CONDITIONER)FIG.153 AIR CONDITIONER (TYPE 1:W/REAR AIR CONDITIONER TO MHYKZE81SDJ121496)FIG.154 AIR CONDITIONER (TYPE 1:W/REAR AIR CONDITIONER FROM MHYKZE81SDJ121497)FIG.155 AIR CONDITIONER (TYPE 2:W/REAR AIR CONDITIONER)FIG.156 AIR CONDITIONER (TYPE 3:W/REAR AIR CONDITIONER)FIG.157 COOLING UNIT (W/REAR AIR CONDITIONER)FIG.158 COMPRESSOR

FIG.111A FLOOR CARPET (TYPE 3)

FIG.111A FLOOR CARPET (TYPE 3)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	DISCONTINUE SUB: 75280B74L00N000	SILENCER, DASH OUTER	1	-
2	DISCONTINUE SUB: 72490B60M00N000	SILENCER, COWL FRONT	1	-	GX
3	09148-05037-000	CLIP	2	Rp18.000
4	09148-05037-000	CLIP	6	Rp18.000	GX
5-1	75110-77M00-PZD	CARPET, FLOOR (BROWN)	1	Rp816.000	GA
5-2	DISCONTINUE SUB: 75110-77M20-PZD	CARPET, FLOOR (BROWN)	1	-	MT:GL,GX
5-3	DISCONTINUE SUB: 75110-77M40-PZD	CARPET, FLOOR (BROWN)	1	-	AT:GL,GX
6	75120-77M00-PZD	CARPET REAR FLOOR (BROWN)	1	Rp406.000
7	09148-05037-000	CLIP	4	Rp18.000
8	09409-10302-R8R	CLIP (BROWN)	5	Rp19.000
9	75130-60M00-PZD	CARPET, LUGGAGE FLOOR (BROWN)	1	Rp160.500	GA
10	09409-10302-R8R	CLIP, LUGGAGE FLOOR CARPET (BROWN)	6	Rp19.000	GA
11	75220-59R00-000	SILENCER, DASH PANEL	1	Rp319.500
12	09409-10302-5PK	CLIP, DASH SIDE (BLACK)	4	Rp18.500
13	75411-59R00-000	PAD, DASH LOWER RH	1	Rp54.000
14	75412-59R00-000	PAD, DASH LOWER LH	1	Rp54.000
15	75471-63J00-000	STOPPER, ACCEL PEDAL	1	Rp34.000
16	09148-05037-000	CLIP	2	Rp18.000
17	75531-59R00-000	PAD, MAIN FLOOR UPPER RR RH	1	Rp114.500
18	75541-59R00-000	PAD, MAIN FLOOR UPPER RR LH	1	Rp114.500
19	99611-60A01-000	SHEET, SILENCER,800X1000X3	0	Rp1.210.000	CUT AS REQUIRED
20	75420-77M00-R8R	BOX, LUGGAGE FLOOR (BROWN)	1	Rp584.000	GL,GX
21	09148-06021-000	•NUT	3	Rp27.500	GL,GX
22	75440-77M00-BWC	COVER, LUGGAGE FLOOR (BROWN)	1	Rp292.500	GL,GX
23	75450-59R00-PZD	FLAP, ASSY LUGGAGE BOX RH (BROWN)	1	Rp189.500	GL,GX
24	75460-59R00-PZD	FLAP, ASSY LUGGAGE BOX LH (BROWN)	1	Rp189.500	GL,GX
25	09122-76006-000	SCREW (6X16)	2	Rp13.000	GL,GX
26	09409-06315-R8R	CLIP, LUGGAGE BOX FLAP (BROWN)	4	Rp15.000	GL,GX
27	09409-07332-R8R	CLIP, LUGGAGE BOX (BROWN)	4	Rp21.500	GL,GX

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
