KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 22 MT CLUTCH (5MT)FIG. 23 MT TRANSMISSION GEAR (5MT)FIG. 24 MT TRANSMISSION CASE (TYPE 1:5MT)FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)FIG. 25 MT GEAR SHIFT FORK (5MT)FIG. 25A AGS CLUTCH (5AGS)FIG. 25B AGS TRANSMISSION GEAR (5AGS)FIG. 25C AGS TRANSMISSION CASE (5AGS)FIG. 25D AGS GEAR SHIFT FORK (5AGS)FIG. 25E AGS ACTUATOR (5AGS)FIG. 26 GEAR SHIFT CONTROL (TYPE 1:5MT)FIG. 26A GEAR SHIFT CONTROL (TYPE 2:5MT)FIG. 26B SELECT LEVER (5AGS)FIG. 27 FRONT DIFFERENTIAL GEAR (5MT)FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 25C AGS TRANSMISSION CASE (5AGS)

FIG. 25C AGS TRANSMISSION CASE (5AGS)
No No. Part Description Qty Price Per Pcs Remarks
1 24711M76ME0-000 CASE, TRANSMISSION RH 1 Rp4.069.500
2 24721M67LE0-000 CASE, TRANSMISSION LH 1 Rp4.779.500
3 24726M76M00-000 PLUG, TRANSMISSION CASE 1 Rp32.000
4 24733M76M00-000 CHANNEL, OIL COUNTERSHAFT 1 Rp11.500
5 24734M76M00-000 CHANNEL, OIL INPUT SHAFT 1 Rp13.000
6 24811M76M00-000 GUTTER, INPUT OIL 1 Rp65.500
7 24821M86J00-000 UNION, BREATHER 1 Rp19.000
8 24825M63J00-000
SUB: 24825M86J00-000		 HOSE, BREATHER 1 Rp6.000
9 24852M76M21-000
SUB: 24852M76M20-000		 PLATE, COUNTERSHAFT RH BEARING 1 Rp8.000
10 24861M76M00-000 MAGNET, OIL CLEANER 1 Rp31.000
11 27991M79G00-000 PLUG, BREATHER HOSE 1 Rp35.000
12 09103M06317-000 BOLT (6X16) 1 Rp6.500
13 09246M16009-000
SUB: 09246M16016-000		 PLUG, T/M OIL FILLER 1 Rp14.500
14 09246M16017-000 PLUG (L:15) 1 Rp24.500
15 01421-1045A-000 STUD BOLT 1 Rp29.500
16 01550-0840A-000
SUB: 01550B0840AN000		 BOLT 14 Rp3.500
17 01550-1040A-000
SUB: 01550B1040AN000		 BOLT 1 Rp7.000
18 01550-1050A-000 BOLT 5 Rp6.000
19 04211M13189-000
SUB: 04211M13149-000		 PIN 2 Rp9.000
20 04211M13189-000
SUB: 04211M13149-000		 PIN 2 Rp9.000
21 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
22 38888-76M00-000 SENSOR ASSY, CLUTCH SPEED 1 Rp1.124.500
23 01550-0616A-000
SUB: 01550B0616AN000		 BOLT 1 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
