FIG. 25B AGS TRANSMISSION GEAR (5AGS)

No	No. Part	Description	Qty	Price Per Pcs
1	24111M76M02-000	SHAFT, TRANSMISSION INPUT	1	Rp1.142.000
2	24114M76M60-000	GEAR, INPUT SHAFT 5TH	1	Rp685.000
3	24151M68K00-000	SEAL, INPUT SHAFT OIL	1	Rp18.000
4	24155M76M00-000	BEARING, INPUT SHAFT RH	1	Rp349.000
5	24165M76M00-000	BEARING, INPUT SHAFT LH	1	Rp210.500
6	24230M76M01-000	GEAR, INPUT SHAFT 3RD	1	Rp1.110.000
7	24240M76M41-000 SUB: 24240M76M40-000	GEAR, INPUT SHAFT 4TH	1	Rp1.478.500
8	24255M76M20-000 SUB: 24255M76M00-000	SPACER, INPUT SHAFT 5TH GEAR	1	Rp75.000
9	24283M76M00-000	BEARING,3RD/4TH GEAR NEEDLE	2	Rp39.500
10	24285M76M00-000	BEARING,5TH GEAR NEEDLE	1	Rp39.500
11	24131M74P00-000	SHAFT, TRANSAXLE COUNTER	1	-
12	24175-76MD0-000 SUB: 24175M76M20-000	BEARING, COUNTERSHAFT RH	1	Rp1.095.500
13	24185M76M00-000	BEARING, COUNTERSHAFT LH	1	Rp336.000
14	24311M76M01-000	GEAR, COUNTERSHAFT 1ST	1	Rp780.000
15	24321M76M01-000	GEAR, COUNTERSHAFT 2ND	1	Rp765.000
16	24331M76M00-000	GEAR, COUNTERSHAFT 3RD	1	Rp468.000
17	24336M76M20-000 SUB: 24336M76M00-000	SPACER,3RD/4TH GEAR	1	Rp29.500
18	24341M76M40-000	GEAR, COUNTERSHAFT 4TH	1	Rp408.000
19	24351M76M60-000	GEAR, COUNTERSHAFT 5TH	1	Rp460.000
20	24381M76M00-000	BEARING,1ST GEAR NEEDLE	1	Rp45.500
21	24382M76M00-000	BEARING,2ND GEAR NEEDLE	1	Rp45.500
22	24385M76M00-000	RING, COUNTERSHAFT LH SNAP	1	Rp10.500
23	24391M76M20-000 SUB: 24391M76M00-000	CIRCLIP, COUNTERSHAFT RH	1	Rp6.000
24-6	24392M76M00-240	CIRCLIP,5TH GEAR (T:2.40)	1	Rp9.500
24-5	24392M76M00-235	CIRCLIP,5TH GEAR (T:2.35)	1	Rp10.500
24-4	24392M76M00-230	CIRCLIP,5TH GEAR (T:2.30)	1	Rp10.500
24-2	24392M76M00-220	CIRCLIP,5TH GEAR (T:2.20)	1	Rp8.500
24-1	24392M76M00-215	CIRCLIP,5TH GEAR (T:2.15)	1	Rp8.500
24-3	24392M76M00-225	CIRCLIP,5TH GEAR (T:2.25)	1	Rp10.500
25	24393M76M00-000	CIRCLIP, COUNTERSHAFT LH	1	Rp6.000
26	24402-68PD0-000 SUB: 24402-76MD0-000	RING,2ND GEAR SYNC	1	Rp501.000
27	24411M67P00-000 SUB: 24411M76M00-000	HUB ASSY, LOW SPEED SYNC	1	Rp149.500
28	24412M76M00-000	HUB ASSY, HIGH SPEED SYNC	1	Rp149.000
29	24413M76M00-000	HUB ASSY,5TH SPEED SYNC	1	Rp144.000
30	24415M76M00-000	PLATE,5TH SPEED SYNC HUB	1	Rp8.500
31	24421M76M00-000	SLEEVE, LOW SPEED SYNC	1	Rp691.500
32	24422M76M00-000	SLEEVE, HIGH SPEED SYNC	1	Rp531.500
33	24423M76M01-000 SUB: 24423M76M00-000	SLEEVE,5TH SPEED SYNC	1	Rp582.000
34	24431M76M00-000	RING,1ST GEAR SYNC	1	Rp176.000
35	24433M76M00-000	RING, HIGH SPEED GEAR SYNC	2	Rp133.500
36	24435M76M00-000	RING,5TH GEAR SYNC	1	Rp120.000
37	24451M76M00-000	CIRCLIP, LOW SPEED SYNC HUB	1	Rp8.000
38	24452M76M00-000	CIRCLIP, HIGH SPEED SYNC HUB	1	Rp7.000
39-1	24453M76M00-200	CIRCLIP,5TH SYNC HUB (T:2.00)	1	Rp6.000
39-2	24453M76M00-205	CIRCLIP,5TH SYNC HUB (T:2.05)	1	Rp8.000
39-3	24453M76M00-210	CIRCLIP,5TH SYNC HUB (T:2.10)	1	Rp8.000
39-4	24453M76M00-215	CIRCLIP,5TH SYNC HUB (T:2.15)	1	Rp8.000
39-5	24453M76M00-220	CIRCLIP,5TH SYNC HUB (T:2.20)	1	Rp8.000
39-6	24453M76M00-225	CIRCLIP,5TH SYNC HUB (T:2.25)	1	Rp6.000
40	24471M76M00-000	KEY, SYNCHRONIZER	9	Rp61.500
41	24550M76M00-000	SHAFT, T/M REVERSE GEAR	1	Rp67.500
42	24560-76MD2-000 SUB: 24560-76MD1-000	GEAR, REVERSE IDLER	1	Rp834.000
43	24565M53M00-000	BOLT, REVERSE SHAFT	1	Rp9.500
44	09161M16012-000	WASHER (16X24X3)	1	Rp6.500
45	09168M08030-000	GASKET (8.2X17X1)	1	Rp6.500
