KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 22 MT CLUTCH (5MT)FIG. 23 MT TRANSMISSION GEAR (5MT)FIG. 24 MT TRANSMISSION CASE (TYPE 1:5MT)FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)FIG. 25 MT GEAR SHIFT FORK (5MT)FIG. 25A AGS CLUTCH (5AGS)FIG. 25B AGS TRANSMISSION GEAR (5AGS)FIG. 25C AGS TRANSMISSION CASE (5AGS)FIG. 25D AGS GEAR SHIFT FORK (5AGS)FIG. 25E AGS ACTUATOR (5AGS)FIG. 26 GEAR SHIFT CONTROL (TYPE 1:5MT)FIG. 26A GEAR SHIFT CONTROL (TYPE 2:5MT)FIG. 26B SELECT LEVER (5AGS)FIG. 27 FRONT DIFFERENTIAL GEAR (5MT)FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 25 MT GEAR SHIFT FORK (5MT)

No	No. Part	Description	Qty	Price Per Pcs
1	25231-70H00-000	FORK,5TH GEAR SHIFT	1	Rp558.000
2	25401-51K00-000	SHAFT, LOW SPEED GEAR SHIFT	1	Rp1.084.500
3	25402-51K00-000	SHAFT, HIGH SPEED GEAR SHIFT	1	Rp1.117.000
4	25251-65G00-000	ARM, REVERSE GEAR SHIFT	1	Rp477.500
5	25255M60B11-000 SUB: 25255M60B01-000	SPRING, REV GEAR SHIFT ARM	1	Rp6.500
6	25260-51K01-000	YOKE,5TH & REV GEAR SHIFT	1	Rp790.000
7	25431-70H00-000	SHAFT,5TH & REV GEAR SHIFT GUIDE	1	Rp254.000
8	DISCONTINUE SUB: 09205-04015-000	SPRING PIN (4.5X20)	1	-
9	06111-10003-000	BALL	1	Rp10.000
10	06111-10003-000	BALL	1	Rp10.000
11	25415-60B02-000	SPRING, LOW SPEED LOCATING	1	Rp27.000
12	25415-67LA0-000	SPRING,5TH & REV LOCATING	1	Rp7.500
13	25425-67LA0-000	SPRING, HIGH SPEED LOCATING	1	Rp7.500
14	25460-65G00-000	LEVER, REVERSE GEAR SHIFT	1	Rp162.000
15	09128M10001-000 SUB: 09128-10002-000	BOLT (10X9)	3	Rp5.500
16	DISCONTINUE SUB: 09205-04015-000	SPRING PIN (4.5X20)	1	-
17	01570-0820B-000 SUB: 01570-0820A-000	BOLT	2	Rp31.000
18	06111-10003-000	BALL	3	Rp10.000
19	08322-0110B-000 SUB: 08322B0110BN000	WASHER	3	Rp4.500
20	24726-67LA0-000 SUB: 24726B67LA0N000	BRACKET, BREATHER HOSE	1	Rp17.000
21	25571M75J00-000	SHAFT, GEAR SHIFT & SELECT	1	Rp64.000
22	09103-08419-000	BOLT (8X25)	1	Rp14.000
23	09403-11314-000	CLAMP	1	Rp24.500
24	25311M68K01-000	PLATE, GEAR SHIFT INTERLOCK	1	Rp72.500
25	25312M68K00-000	SPRING, GEAR SHIFT INTERLOCK	1	Rp7.500
26	25541M68K40-000	LEVER, GEAR SHIFT & SELECT	1	Rp144.000
27	09205M03016-000	SPRING PIN (3.5X28)	1	Rp4.500
28	09205M06022-000 SUB: 09205M06004-000	SPRING PIN (6X28)	1	Rp6.500
29	06111M07004-000	BALL	2	Rp3.000
30	25576M75J01-000	SPRING,1ST & 2ND SELECT	1	Rp5.000
31	25577M75J00-000	SPRING,5TH & REVERSE SELECT	1	Rp6.500
32	09383M12002-000	E RING	3	Rp12.500
33	08212M14301-000	WASHER	4	Rp4.500
34	25581M86JA1-000	CAM,5TH & REVERSE GEAR SHIFT	1	Rp40.000
35	25582M75J00-000	GUIDE,5TH & REV GEAR SHIFT CAM	1	Rp12.000
36	25583M68K00-000	SPRING, CAM GUIDE RETURN	1	Rp6.500
37	09205M03035-000	SPRING PIN (3X22)	1	Rp6.500
38	09205M04025-000	SPRING PIN	1	Rp7.500
39	25584-67LA0-000	BOLT,5TH TO REV INTLK GUIDE	1	-
40	08322M0108A-000	WASHER	1	Rp5.500
41	DISCONTINUE SUB: 25321-86G00-000	BOLT, GEAR SHIFT INTERLOCK	1	-
42	08322-0110B-000 SUB: 08322B0110BN000	WASHER	1	Rp4.500
43	25610M68K41-000	LEVER, SHIFT CABLE	1	Rp119.500
44	25620M68K01-000	LEVER, SELECT CABLE	1	Rp77.000
45	09205M03049-000 SUB: 09205M03037-000	SPRING PIN (3X25)	1	Rp6.500
46	09205M06016-000	SPRING PIN (6X25)	1	Rp4.500
47	25558M75J00-000	BUSH, SELECT LEVER BOSS	2	Rp6.500
48	25559M75J01-000	BUSH, SELECT LEVER SHAFT	1	Rp12.500
49	09160-08151-000 SUB: 09160M08151-000	WASHER (8.5X26X1.6)	1	Rp16.500
50	08310-0008A-000 SUB: 08310M0008A-000	NUT	1	Rp12.500
51	08321M01083-000 SUB: 08321M0108A-000	WASHER	1	Rp11.000
52	25624M68K00-000	BOOT, SELECT LEVER INSIDE	1	Rp6.000
53	25625M68K00-000	BOOT, SELECT LEVER OUTSIDE	1	Rp6.000
54	25630M68K02-000 SUB: 25630M68K03-000	BRACKET, SELECT & CLUTCH	1	Rp92.000
55	01550-0825A-000 SUB: 01550B0825AN000	BOLT	1	Rp3.500
56	25651M68K00-000	BOOT, SHIFT & SELECT SHAFT OIL	1	Rp10.500
57	09283M14005-000	OIL SEAL (14X22X6)	1	Rp9.000
58	25573M75J01-000	CASE, GEAR SHIFT GUIDE	1	Rp127.000
59	09103-08366-000	BOLT (8X45)	1	Rp25.500
60	01550-0825A-000 SUB: 01550B0825AN000	BOLT	2	Rp3.500
