FIG. 25A AGS CLUTCH (5AGS)

FIG. 25A AGS CLUTCH (5AGS)
No No. Part Description Qty Price Per Pcs Remarks
1 22100-84M00-000 COVER ASSY, CLUTCH 1 Rp1.173.000
2 22400-84M02-000
SUB: 22400-84M00-000		 DISC, CLUTCH 1 Rp1.251.000
3 01550-0816A-000
SUB: 01550B0816AN000		 BOLT (8X16) 6 Rp6.000
4 23260M68K01-000 SHAFT, CLUTCH RELEASE 1 Rp118.000
5 23263M74L00-000 SEAL, CLUTCH RELEASE SHAFT 1 Rp22.000
6 23264M60B00-000 BUSH, CLUTCH RELEASE SHAFT 1 Rp23.500
7 23264M60B20-000 BUSH, CLUTCH RELEASE SHAFT 1 Rp25.000
8 09269-28004-000
SUB: 09269B28004N000		 BEARING, CLUTCH RELEASE 1 Rp240.500
9 23266M76ME0-000 ARM, CLUTCH RELEASE 1 Rp246.000
10 09205-03019-000 SPRING PIN (3X10) 1 Rp9.500
11 01550-0830A-000
SUB: 01550B0830AN000		 BOLT 1 Rp4.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
