KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 22 MT CLUTCH (5MT)FIG. 23 MT TRANSMISSION GEAR (5MT)FIG. 24 MT TRANSMISSION CASE (TYPE 1:5MT)FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)FIG. 25 MT GEAR SHIFT FORK (5MT)FIG. 25A AGS CLUTCH (5AGS)FIG. 25B AGS TRANSMISSION GEAR (5AGS)FIG. 25C AGS TRANSMISSION CASE (5AGS)FIG. 25D AGS GEAR SHIFT FORK (5AGS)FIG. 25E AGS ACTUATOR (5AGS)FIG. 26 GEAR SHIFT CONTROL (TYPE 1:5MT)FIG. 26A GEAR SHIFT CONTROL (TYPE 2:5MT)FIG. 26B SELECT LEVER (5AGS)FIG. 27 FRONT DIFFERENTIAL GEAR (5MT)FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)

FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)
No No. Part Description Qty Price Per Pcs Remarks
1 24711-67LA0-000
SUB: 24711B67LA0N000		 CASE, TRANSMISSION RH 1 Rp1.442.500
2 24721-67LA0-000
SUB: 24721B67LA0N000		 CASE, TRANSMISSION LH 1 Rp2.759.500
3 24725-65G40-000 PLATE, T/M LH CASE 1 Rp186.500
4 24728-65G60-000 SCREW, T/M LH CASE PLATE 5 Rp31.000
5 24728-63J00-000
SUB: 24728-67LA0-000		 SCREW, T/M LH CASE PLATE 1 Rp29.500
6 24730M67LA0-000 COVER, TRANSMISSION SIDE 1 -
7 24810-67LA0-000
SUB: 24810B67LA0N000		 GUTTER, INPUT OIL 1 Rp10.500
8 24815-67LA0-000
SUB: 24815B67LA0N000		 PLATE, BREATHER CASE 1 Rp12.000
9 24855-60K00-000 HOOK, TRANSMISSION 1 Rp8.500
10 27991-77M00-000
SUB: 27991B77M00N000		 PLUG, BREATHER HOSE 1 Rp6.500
11 09103-06285-000
SUB: 09103B06285N000		 BOLT (6X12) 1 Rp9.000
12 09103-06285-000
SUB: 09103B06285N000		 BOLT (6X12) 2 Rp9.000
13 09135-06027-000 BOLT (6X12) 6 Rp15.000
14 DISCONTINUE
SUB: 09135-08007-000		 BOLT (8X16) 2 -
15 09246-16021-000
SUB: 09246-16010-000		 PLUG 1 Rp48.000
16 09246-16021-000
SUB: 09246-16010-000		 PLUG 1 Rp48.000
17 09352-70114-110 HOSE (7X11X110) 1 -
18 09364-08004-000 UNION 1 Rp13.000
19 01421-1045A-000 STUD BOLT 1 Rp29.500
20 01550-0840A-000
SUB: 01550B0840AN000		 BOLT 13 Rp3.500
21 01550-1040A-000
SUB: 01550B1040AN000		 BOLT 1 Rp7.000
22 01550-1050A-000 BOLT 5 Rp6.000
23 04211M13189-000
SUB: 04211M13149-000		 PIN 2 Rp9.000
24 04211M13189-000
SUB: 04211M13149-000		 PIN 2 Rp9.000
25 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
26 37610-76G10-000 SWITCH ASSY, BACK UP LAMP 1 Rp166.500
27 09280-11002-000 •O RING (D:1.9,ID:11.4) 1 Rp10.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
