  5. FIG. 23 MT TRANSMISSION GEAR (5MT)

KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 22 MT CLUTCH (5MT)FIG. 23 MT TRANSMISSION GEAR (5MT)FIG. 24 MT TRANSMISSION CASE (TYPE 1:5MT)FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)FIG. 25 MT GEAR SHIFT FORK (5MT)FIG. 25A AGS CLUTCH (5AGS)FIG. 25B AGS TRANSMISSION GEAR (5AGS)FIG. 25C AGS TRANSMISSION CASE (5AGS)FIG. 25D AGS GEAR SHIFT FORK (5AGS)FIG. 25E AGS ACTUATOR (5AGS)FIG. 26 GEAR SHIFT CONTROL (TYPE 1:5MT)FIG. 26A GEAR SHIFT CONTROL (TYPE 2:5MT)FIG. 26B SELECT LEVER (5AGS)FIG. 27 FRONT DIFFERENTIAL GEAR (5MT)FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 23 MT TRANSMISSION GEAR (5MT)

FIG. 23 MT TRANSMISSION GEAR (5MT)
No No. Part Description Qty Price Per Pcs Remarks
1 24111-67LA0-000 SHAFT, TRANSMISSION INPUT 1 Rp1.183.000
2 24114-67LA0-000 GEAR, INPUT SHAFT 5TH 1 Rp1.155.500
3 24119-67LA0-000
SUB: 24119B67LA0N000		 SPACER, INPUT SHAFT 5TH GEAR 1 Rp35.500
4 24151-67LA0-000
SUB: 24151B67LA0N000		 SEAL, INPUT SHAFT OIL 1 Rp13.000
5 24155-67LA0-000
SUB: 24155B67LA0N000		 BEARING, INPUT SHAFT RH 1 Rp103.500
6 24165-67LA0-000
SUB: 24165B67LA0N000		 BEARING, INPUT SHAFT LH 1 Rp349.000
7 24230-67LA0-000 GEAR, INPUT SHAFT 3RD 1 Rp1.160.000
8 24240-67LA0-000 GEAR, INPUT SHAFT 4TH 1 Rp1.324.000
9 24283-67LA0-000
SUB: 24283B67LA0N000		 BEARING,3RD GEAR NEEDLE 1 Rp25.500
10 24284-67LA0-000
SUB: 24284B67LA0N000		 BEARING,4TH GEAR NEEDLE 1 Rp40.500
11 24285-67LA0-000
SUB: 24285B67LA0N000		 BEARING,5TH GEAR NEEDLE 2 Rp26.500
12 24131-67LA0-000 SHAFT, TRANSMISSION COUNTER 1 Rp2.200.500
13 24175-67LA0-000
SUB: 24175B67LA0N000		 BEARING ASSY, COUNTERSHAFT RH 1 Rp227.500
14 24185-67LA0-000
SUB: 24185B67LA0N000		 BEARING ASSY, COUNTERSHAFT LH 1 Rp207.000
15 24311-67LA0-000 GEAR, COUNTERSHAFT 1ST 1 Rp1.088.000
16 24321-67LA0-000 GEAR, COUNTERSHAFT 2ND 1 Rp982.500
17 24331-67LA0-000 GEAR, COUNTERSHAFT 3RD 1 Rp1.176.500
18 24336-67LA0-000
SUB: 24336B67LA0N000		 SPACER,3RD & 4TH GEAR 1 Rp29.500
19 24341-67LA0-000 GEAR, COUNTERSHAFT 4TH 1 Rp1.176.500
20 24351-67LA0-000 GEAR, COUNTERSHAFT 5TH 1 Rp770.500
21 24381-67LA0-000
SUB: 24381B67LA0N000		 BEARING,1ST GEAR NEEDLE 1 Rp25.500
22 24382-67LA0-000
SUB: 24382B67LA0N000		 BEARING,2ND GEAR NEEDLE 2 Rp24.500
23 09159-16014-000 NUT 1 Rp42.000
24-14 09160M33006-000 SHIM (T:1.15) 0 Rp11.000
24-13 09160M33005-000 SHIM (T:1.10) 0 Rp10.500
24-12 09160M33004-000 SHIM (T:1.05) 0 Rp11.000
24-11 09160M33003-000 SHIM (T:1.00) 0 Rp11.000
24-10 09181M33009-000 SHIM (T:0.95) 0 Rp8.500
24-9 09181M33008-000 SHIM (T:0.90) 0 Rp8.500
24-8 09181M33007-000 SHIM (T:0.85) 0 Rp8.500
24-6 09181M33005-000 SHIM (T:0.75) 0 Rp8.500
24-5 09181M33004-000 SHIM (T:0.70) 0 Rp8.500
24-4 09181M33003-000 SHIM (T:0.65) 0 Rp8.500
24-3 09181M33002-000 SHIM (T:0.60) 0 Rp8.500
24-2 09181M33001-000 SHIM (T:0.55) 0 Rp8.500
24-1 DISCONTINUE
SUB: 09170M33421-050		 SHIM (T:0.50) 0 -
24-7 09181M33006-000 SHIM (T:0.80) 0 Rp8.500
25 24400-67LA0-000 HUB ASSY, LOW SPEED SYNC 1 Rp1.630.500
26 24410-67LA1-000
SUB: 24410-67LA0-000		 HUB ASSY, HIGH SPEED SYNC 1 Rp1.305.000
27 24420-67LA0-000 HUB ASSY,5TH SPEED SYNC 1 Rp1.096.000
28 24430-83E01-000 RING ASSY,2ND GEAR SYNC 1 Rp1.210.000
29-1 24431-60B00-000 RING,1ST GEAR SYNC 1 Rp216.500 TYPE 1
29-2 24431-67LA0-000 RING,1ST GEAR SYNC 1 Rp71.000 TYPE 2
30-1 24432-60B20-000 RING, HIGH SPEED SYNC 2 Rp213.500 TYPE 1
30-2 24432-67LA0-000 RING, HIGH SPEED SYNC 2 Rp64.500 TYPE 2
31-2 24434-67LA0-000 RING,5TH SPEED SYNC 1 Rp59.500 TYPE 2
31-1 24432-84041-000 RING,5TH SPEED SYNC 1 Rp268.000 TYPE 1
32 24441-67LA0-000
SUB: 24441B67LA0N000		 SPRING, LOW SPEED SYNC 2 Rp14.000
33 24442-67LA0-000
SUB: 24442B67LA0N000		 SPRING, HIGH SPEED SYNC 2 Rp9.000
34 24443-67LA0-000
SUB: 24443B67LA0N000		 SPRING,5TH SPEED SYNC 2 Rp11.000
35 24452-60B00-000 CIRCLIP, LOW SPEED SYNC HUB 1 Rp26.500
36 24452-60B00-000 CIRCLIP, HIGH SPEED SYNC HUB 1 Rp26.500
37 24471-60B00-000 KEY, LOW SPEED SYNC 3 Rp29.000
38 24472-60B00-000 KEY, HIGH SPEED SYNC 3 Rp25.000
39 24473-72J00-000 KEY,5TH SPEED SYNC 3 Rp28.500
40 09380M19005-000
SUB: 09380M19004-000		 CIRCLIP 1 Rp5.500
41 24415-60B51-000 PLATE,5TH SYNC HUB 1 Rp49.000
42 24550-67LA0-000
SUB: 24550B67LA0N000		 SHAFT, T/M REVERSE GEAR 1 Rp49.500
43 24560-63B41-000 GEAR, REVERSE IDLER 1 Rp1.099.500
44 24565-60B00-000 BOLT, REVERSE SHAFT 1 Rp21.500
45 09161M16010-000 WASHER (16X24X3) 1 Rp5.500
46 09168M08030-000 GASKET (8.2X17X1) 1 Rp6.500
