KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 22 MT CLUTCH (5MT)FIG. 23 MT TRANSMISSION GEAR (5MT)FIG. 24 MT TRANSMISSION CASE (TYPE 1:5MT)FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)FIG. 25 MT GEAR SHIFT FORK (5MT)FIG. 25A AGS CLUTCH (5AGS)FIG. 25B AGS TRANSMISSION GEAR (5AGS)FIG. 25C AGS TRANSMISSION CASE (5AGS)FIG. 25D AGS GEAR SHIFT FORK (5AGS)FIG. 25E AGS ACTUATOR (5AGS)FIG. 26 GEAR SHIFT CONTROL (TYPE 1:5MT)FIG. 26A GEAR SHIFT CONTROL (TYPE 2:5MT)FIG. 26B SELECT LEVER (5AGS)FIG. 27 FRONT DIFFERENTIAL GEAR (5MT)FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)
No No. Part Description Qty Price Per Pcs Remarks
1 26121M68K00-000 RING, EXCITER 1 Rp64.000
2 27331M55K00-000 PINION, DIFFERENTIAL 2 Rp163.500
3 27341M68K02-000 GEAR, DIFFERENTIAL 2 Rp238.000
4 27351M76M20-000
SUB: 27351M76M00-000		 SHAFT, DIFFERENTIAL PINION 1 Rp75.000
5 27411M76M00-000 CASE, DIFFERENTIAL 1 Rp730.500
6 27431M74L00-000 SEAL, DIFFERENTIAL SIDE OIL RH 1 Rp125.500
7 27432M74L00-000 SEAL, DIFFERENTIAL SIDE OIL LH 1 Rp125.500
8 27511M83EE0-000 GEAR, FINAL 1 -
9 27524-75J00-000
SUB: 27524B75J00N000		 BEARING, DIFFERENTIAL SIDE 2 Rp122.000
10 09103-10189-000 BOLT (10X23) 8 Rp29.000
11-2 09181M35157-000 WASHER (T:0.65) 0 Rp9.000
11-10 09160M35023-000 WASHER (T:1.05) 0 Rp10.000
11-9 09160M35018-000 WASHER (T:1.00) 0 Rp20.500
11-8 09160M35022-000 WASHER (T:0.95) 0 Rp10.000
11-7 09160M35021-000 WASHER (T:0.90) 0 Rp10.000
11-6 09181M35159-000 WASHER (T:0.85) 0 Rp9.000
11-5 DISCONTINUE
SUB: 09160B35013N000		 WASHER (T:0.80) 0 -
11-4 09181M35158-000 WASHER (T:0.75) 0 Rp9.000
11-3 09160M35014-000 WASHER (T:0.70) 0 Rp10.000
11-1 09160M35015-000 WASHER (T:0.60) 0 Rp6.500
12 09164M17006-000 WASHER (17.3X32X1) 2 Rp8.000
13 09164M35003-000 WASHER 2 -
14 09205M05007-000 SPRING PIN (5X36) 1 Rp5.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
